We cannot ship this product to California, under Title 20 CCR section 1605.3(g)(5)Product Type: Capacitor StartHP: 1-1/2RPM: 3450Volts: 115/230Amps: 17.5/8.75Hz: 60Phase: 1Frame: 48YEnclosure Type: ODP (Open Dripproof)Mounting: Square FlangeMotor Diameter: 5-5/8"Shaft Diameter: ThreadedRotation: CCW Pump EndNumber of S
Attributes
| Key ^ | Value |
|---|---|
| <span style="color | #ff0000;">We cannot ship this product to California, under <strong>Title 20 CCR section 1605.3(g)(5)</strong></span> |
| Amps | 17.5/8.75 |
| Bearings | Ball |
| Capacitor | Included |
| Duty Cycle | Continuous |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 48Y |
| HP | 1-1/2 |
| Hz | 60 |
| Insulation Class | B |
| Maximum Ambient Temperature | 50? C |
| Motor Diameter | 5-5/8" |
| Mounting | Square Flange |
| Number of Speeds, Phase | 1 |
| Product Type | Capacitor Start |
| Rotation | CCW Pump End |
| RPM | 3450 |
| Service Factor (SF) | 1.10 |
| Shaft Diameter | Threaded |
| Ship Weight | 28 lbs. |
| Thermal Protection | Automatic |
| USQG1152A is listed in Century's cross reference as a substitute for the following | A.O. Smith C48AA07A01, A.O. Smith C48AA43A01, A.O. Smith C48L2PA103C1, A.O. Smith USQG1152 |
| Volts | 115/230 |
