mpn:
brand:
manufacturer:
MPN:
Description:
211-1167-002 EATON | Search our online catalog of Mobile Hydraulics. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key ^ | Value |
|---|---|
| Additional ports, Flow amplification, Unit type21 | None |
| Application | Agricultural Equipment, Forestry Equipment, Construction Equipment, Turf Care Equipment, Industrial Equipment |
| Design code11 | 2 |
| Eccn | EAR99 |
| Flow rate12 | 25 LPM |
| Fluid compatibility13 | See Eaton Technical Bulletin 3-401 |
| Housing material | Ductile Iron |
| Icc2 | Steering Control Unit (SCU) |
| Identification | Eaton Product Number On Nameplate |
| Inlet or load sense relief valve setting | 0 bar |
| Inlet pressure rating, Working pressure max | 172 bar |
| Input torque | Standard |
| Integral valves | Yes |
| Load circuit | Non Reaction |
| Main displacement | 295 cubic centimetre per revolution |
| Maximum back pressure | 21 bar |
| Maximum flow rate | 45 litre per minute |
| Mechanical interface | Internal Involute Spline, 12 Tooth 16/32 Dp 30 Degree Pa |
| Model Code | ABU55A570AA010000DAAC3A0AB10B |
| Mounting threads | 2X .375-24 UNF-2B Port Face 4X .375-16 UNC-2B Mounting Face |
| Neutral circuit | Open Center |
| Paint | Black |
| Ports | 4X .750-16 UNF-2B SAE O-Ring Port |
| Product height | 3.70 |
| Product height uom, Product length uom, Product width uom | inch |
| Product length | 6.54 |
| Product trade name | Series 3,6 and 12 |
| Product weight | 14.20 |
| Product weight uom | pound |
| Product width | 5.67 |
| Recommended filtration level | ISO 18/13 Cleanliness |
| Return pressure rating | 10 bar |
| Special features17 | Low Torque Shaft Seal |
| Sub brand | Char-Lynn |
| Valve options | Manual Steering Check Valve |
| Viscosity recommendation | 120 Saybold universal second |
| Working temperature max | 93 degree Celsius |
