Bussmann DRQ125-6R8-R

B07346F899

BUSSMANN DRQ125-6R8-R DRQ Series 6.8 uH ?20 % Tolerance 6.64 A Shielded SMT Power Inductor - 600 item(s)

BUSSMANN DRQ125-6R8-R DRQ Series 6.8 uH ?20 % Tolerance 6.64 A Shielded SMT Power Inductor - 600 item(s)zoom

Attributes

Key Value
Alternate Part No.704-DRQ125-6R8-R
Body dimensions12.5x12.5x6mm
BrandCoiltronics / Eaton, Co.
Case Height6 mm
Case Length12.5 mm
Case Width12.5 mm
CategoryInductors, Coils, Chokes
Core MaterialFerrite
Current Rating - Parall.6.64 A
Current Rating - Series3.32 A
Current Saturation - Pa.8.68 A
Current Saturation - Se.4.34 A
DC Resistance (DCR) - P.12.3mOhm
DC Resistance (DCR) - S.49.2mOhm
Depth12.5mm
Dimensions12.5 x 12.5 x 6mm
Height0.236" (6.00mm), 6mm
Inductance6.8 ?H, 6.8?H, 6.8 uH, .
Inductance - Connected .6.588 ?H
Inductance - Connected .26.35 ?H
Inductor ConstructionWire-Wound
Length12.5mm
ManufacturerEATON ELECTRONICS, Eaton
Manufacturer Part No.DRQ125-6R8-R
Maximum dc Current8.68A
Maximum DC Current8.68 A
Maximum DC Resistance12.3 mOhms, 49.2m?
Maximum Operating Tempe.+125?C
Maximum Self Resonant F.100kHz
MfrEaton - Electronics Div.
Minimum Operating Tempe.-40?C
MountingSMD
Mounting TypeSurface Mount
Number of Coils2
Operating current6.64A
Operating Temperature-40?C ~ 125?C
Operating temperature-40...125?C
Operating Temperature R.- 40 C to + 125 C
PackageTape & Reel (TR)
Package / CaseNonstandard
Package/Case0125
PackagingReel
ProductInductors
Product CategoryFixed Inductors
Product StatusActive
Ratings-
Resistance12.3m?
Saturation current8.68A
SeriesDRQ, DRQ Series
ShieldedYes
ShieldingShielded
Size / Dimension0.492" L x 0.492" W (12.
StockStock
TerminationSMD
Termination StyleSMD/SMT
Test Frequency100 kHz
ToleranceTolerance, ?20%, 20 %
TypeDual Winding Inductor, .
Type of inductorwire
Unit Weight4.082 g

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomTMEDRQ125-6R8-R0.921480EATON ELECTRONICS0.92 @ 100
HotendaH21187370.969600100Eaton (formerly Cooper Bussmann)0.969 @ 600
WaldomEaton Electronics DRQ125-6R8-R0.99600100Eaton Electronics0.99 @ 600
Digi-Key6672511.15271100Eaton - Electronics Division1.1527 @ 100
thumbzoomNewark54K44341.2600100EATON COILTRONICS1.2 @ 100
us.rs-online.com700379751.56600100Eaton Electronics1.56 @ 600
thumbzoomswatee.comDRQ125-6R8-R4.141591Eaton4.14 @ 100
