mpn:
brand:
manufacturer:
MPN:
Description:
Capacitor,Alum Electrolytic,800 uF,-10,+50%,450 VDC,Screw Terminal,2x4.625in
Weight:
0.04
Weight:
0.04 LB
Preferred Price:
118.58
Price:
118.58
Min Simple Price:
64.8
Absolute Min Price:
92.01
Min Price:
92.01
Dimensions:
[5.0, 5.0, 5.0]
qty:
21
simpleSku:
NDE3MA:::CGS801T450V4L
sku:
NDE3MA::9O:CGS801T450V4L@y0
condition:
11
seller:
Digi-Key
amzMan:
cornell dubilier
HazMat:
False
DropShip:
False
Attributes
| Key | Value |
|---|---|
| Alternate Part No. | 539-CGS450V800 |
| Applications | General Purpose |
| Brand | Cornell Dubilier |
| Capacitance | 800 ?F, 800 uF |
| Capacitance Range | 100 to 999 uF |
| Case Size | Dia. 2 x L 4.625 in ; Dia. 50.8 x L 117.475 mm |
| Category | Capacitors |
| Configuration | Radial ; Can |
| Description | CAP ALUM 800UF 450V SCREW |
| Detailed Description | 800 ?F 450 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 108mOhm @ 120Hz 2000 Hrs @ 85?C |
| Diameter | 50.8 mm (2 in) |
| Digi-Key Part Number | 338-3557-ND |
| Element Material | Aluminum Electrolytic |
| ESR | 108 mOhms |
| ESR (Equivalent Series Resistance) | 108mOhm @ 120Hz |
| Height | 122.22 mm |
| Height - Seated (Max) | 4.625" (117.48mm) |
| Lead Spacing | -, 22 mm (0.875 in) |
| Leakage Current | 6 mA |
| Length | 117.5 mm (4.625 in) |
| Lifetime @ Temp. | 2000 Hrs @ 85?C |
| Manufacturer | Cornell Dubilier Electronics (CDE), Cornell Dubilier |
| Manufacturer Part No. | CGS801T450V4L |
| Manufacturer Product Number | CGS801T450V4L |
| Manufacturer Standard Lead Time | 16 Weeks |
| Maximum Operating Temperature | + 85 C, 85 C |
| Mfr | Cornell Dubilier Electronics (CDE) |
| Minimum Operating Temperature | - 40 C, -40 C |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40?C ~ 85?C |
| Package | Bulk |
| Package / Case | Radial, Can - Screw Terminals |
| Packaging | Bulk |
| Polarization | Polar |
| Product | Computer Grade Electrolytic Capacitors |
| Product Category | Aluminium Electrolytic Capacitors - Screw Terminal |
| Product Status | Active |
| Ratings | - |
| Ripple Current | 4.4 A (RMS) (Max.) @ 120 Hz, +85 ?C, 4.4 A |
| Ripple Current @ High Frequency | 6.6 A @ 10 kHz |
| Ripple Current @ Low Frequency | 4.4 A @ 120 Hz |
| Series | CGS, CGS Series |
| Shelf Life | 1000 hr |
| Size / Dimension | 2.000" Dia (50.80mm) |
| Surface Mount Land Size | - |
| Surge Voltage | 525 VDC |
| Termination | Stud |
| Termination Style | Screw |
| Test Condition ESR | @ 120 Hz |
| Tolerance | -10%, +50%, -10% ; 50% %, - 10 %, + 50 % |
| Voltage - Rated | 450 V |
| Voltage Rating | 450 VDC |
| Voltage Rating DC | 450 V |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Digi-Key | 1596323 | 64.8 | 64.8 | 1 | In Stock | Cornell Dubilier Electronics (CDE) | 64.8 @ Qty: 1+ | ||
| Hotenda | H275050 | 65.17 | 65.17 | 1 | 31 | Cornell Dubilier Electronics | 65.17 @ Qty: 1+ | |||
 | Newark | 72K7276 | 65.79 | 197.37 | 6 | In Stock | CORNELL DUBILIER | 65.79 @ Qty: 5+ | ||
| us.rs-online.com | 70187010 | 68.43 | 68.43 | 1 | 22 | Cornell-Dubilier | 68.43 @ Qty: 1+ | |||
 | swatee.com | CGS801T450V4L | 97.89 | 97.89 | 1 | 1 | Cornell Dubilier | 97.89 @ Qty: 1+ |
