Attributes
| Key ^ | Value |
|---|---|
| Altitude | 2000 meter max |
| Basic Accuracy | 1.0 % |
| Cleaning | water-dampened cloth |
| Frequency Range | DC Only |
| Installation Category | CAT II |
| Insulation Voltage | 2500 VDC |
| Isolation Voltage | 2500KVRMS/1mA/1Sec |
| Linearity | 10% to 100% FS |
| MTBF | Greater than 100 K hours |
| Operating Temperature | 0?C to +50?C |
| Output Load | 4-20 mADC - 0 to 500 ? 0-5 VDC - 2K ? or Greater |
| Pollution Degree | 2 |
| Relative Humidity | 5% to 95%, Non-Condensing |
| Response Time | 250 ms. max |
| Supply Current | Typical 35mA; Max 40mA |
| Supply Voltage | 24 VDC ?10% |
| Thermal Drift | 500 PPM/?C |
| Torque Specs | 3.0-inch lbs. (0.4Nm) |
| Vibration Tested To | IEC 60068-2-6,1995 |
| Weight | 0.5 lbs |
