871399 DANFOSS | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key | Value |
|---|---|
| Actuation identification | Solenoid B |
| Actuation type | Solenoid Operated |
| Actuator identification | Flag with Standard Build as Per ANSI B93 9 |
| Application | Die casting & foundry, Machine tool, Marine/Offshore, Press, Primary metal, paper, Test equipment & simulation, Turbine control (wind, steam, water) |
| Body material7 | Gray Iron |
| Build orientation | Solenoid at B Port End |
| Build type | Spring offset end to end |
| Coil rating | 24 Volt DC |
| Coil type | ISO 4400 mounting |
| Design code11 | 20 |
| Diode | None |
| Eccn | EAR99 |
| Electrical connector | ISO 4400 (Din 43650) Connector |
| Flow rate12 | 120 litre per minute |
| Fluid cleanliness | 19/17/14 micron |
| Fluid compatibility13 | Petroleum Oils |
| Function | Directional Control Valve |
| Icc2 | IV Directional Control Valves |
| Interface | ISO4401-AC-05-4-A/NFPA D05 |
| Leakage | Standard |
| Light | No |
| Manual override | Plain |
| Model Code | DG4V 5 0A V M U H6 20 |
| Pressure rating | 315 bar |
| Product height | 4.45 |
| Product height uom | inch |
| Product length | 8.46 |
| Product length uom | inch |
| Product trade name | DG4V-5 20 Design |
| Product weight | 10.60 |
| Product weight uom | pound |
| Product width | 2.76 |
| Product width uom | inch |
| Seal material16 | Buna-N |
| Size | D05 |
| Special features17 | None |
| Spool center condition | B Port End |
| Spool monitor switch | None |
| Spring arrangement | A |
| Stage | Single Stage |
| Sub brand | Vickers |
| Tank port rating | 207 bar |
| Valve mount type | Subplate/manifold mounted |
| Working temperature max | 70 degree Celsius |
| Working temperature min | -20 degree Celsius |
