mpn:
brand:
manufacturer:
MPN:
Weight:
0.3125
Weight:
0.3125 LB
Preferred Price:
163.71
Price:
163.71
Min Simple Price:
89.46284756
Absolute Min Price:
127.03
Min Price:
127.03
Dimensions:
[10.0, 7.0, 5.0]
qty:
21
simpleSku:
MTI3MQ:::1MBG4
sku:
MTI3MQ::W2:1MBG4@y0
condition:
11
seller:
grainger.ca
amzMan:
dayton
HazMat:
False
DropShip:
False
Attributes
| Key | Value |
|---|---|
| Agency Compliance | UL/CSA |
| Ambient (C) | 40 |
| Application | Conveyor Toasters, X-ray Equipment, Pumps, Ingredient Motors, Water Softeners, Vending, Food and Restaurant Equipment, Amusement Devices, Valve Actuators, Security Systems, Displays |
| Bearings | Needle on Case, Ball and Porous Bronze on Motor |
| Brand | Dayton |
| Current Stock | 18 |
| Dimension A | 4.2 in |
| Dimension B | 1.57 in |
| Enclosure | Open |
| Full Load Amps | 0.62 |
| Full Load Torque (In.-Lbs.) | 50.0 |
| Gear Case | Zinc Die Cast |
| Gear Case Material | Die Cast Zinc |
| Gear Ratio | 504:1 |
| Gear Type | Spur |
| Gearmotor Brake Type | None |
| Gearmotor Enclosure | Open |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Phase | 1 |
| Gearmotor Rotation | CW |
| Gearmotor Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type | AC Gearmotor |
| Gearmotor Voltage | 115V AC, 115 V AC |
| Gears | All Spur Gears |
| Housing | Die Cast Zinc |
| Hz | 60 |
| Includes | Cooling Fan and Spring Clip |
| Input HP | 1/111 |
| Insulation Class | A |
| International Shipping | No |
| Item | AC Gearmotor |
| Length Less Shaft | 4 3/4 in, 4-3/4" |
| Length Less Shaft (In.) | 4-3/4 |
| Lubrication | Grease, Grease Filled |
| Max. Ambient Temp. | 40 Degrees C |
| Max. Torque | 50 in.- lbs., 50.0 in-lb |
| Motor Type | Shaded Pole |
| Mount Hole Center-to-Center Length | 2.38 in |
| Mount Hole Center-to-Center Width | 2.38 in |
| Mounting | All Position |
| Mpn | 1MBG4 |
| Nameplate RPM | 6.7, 6.7 RPM, 7 |
| No Load RPM | 7 |
| Output Shaft Diameter | 5/16 in |
| Output Shaft Height | 1.41 in |
| Output Shaft Length | 3/4 in |
| Overall Height | 2.92 in |
| Overall Width | 3.16 in |
| Overhung Load | 41 lbs. |
| Overhung Load (Lb.) | 41 |
| Phase | 1 |
| Rotation | CW |
| Seals | Gasketed Gear Case |
| Shaft Dia. (Dimension U) | 5/16" |
| Shaft Dimensions (In.) | 5/16 x 3/4 |
| Shaft Length (Dimension V) | .75", 0.75" |
| Shaft Orientation | Parallel |
| Ship Weight | 5 lbs. |
| SKU | ZO-G0912581 |
| Standards | UL/CSA/CE |
| SubCategory | Power Transmission |
| Thermal Protection | Auto |
| Type | Parallel Shaft |
| UPC | 190735146408 |
| Voltage Rating | 115 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| grainger.ca | DMD1MBG4 | 89.46284756 | 89.46284756 | 1 | In Stock | DAYTON | 1.0 | 89.46284756 @ Qty: 1+ | ||
 | Zoro | G0912581 | 110.99 | 110.99 | 1 | 26 | Dayton | 4.01 | 110.99 @ Qty: 1+ | |
 | simsupply.com | ZO-G0912581 | 131.45 | 131.45 | 1 | 18 | Dayton | 131.45 @ Qty: 1+ | ||
 | sustainablesupply.com | C1661145 | 155.82 | 155.82 | 1 | In Stock | Dayton | 4.01 | 155.82 @ Qty: 1+ | |
| emotorpro.com | 1MBG4 | 173.51 | 173.51 | 1 | In Stock | Dayton | 5.0 | 173.51 @ Qty: 1+ | ||
 | Raptor Supplies | AB2JEH | 181.8487125 | 181.8487125 | 1 | In Stock | DAYTON | 181.8487125 @ Qty: 1+ |
