Attributes
| Key | Value |
|---|---|
| Agency Compliance | UL/CSA |
| Ambient (C) | 40 |
| Application | Conveyor Toasters, X-ray Equipment, Pumps, Ingredient Motors, Water Softeners, Vending, Food and Restaurant Equipment, Amusement Devices, Valve Actuators, Security Systems, Displays |
| Bearings | Needle on Case, Ball and Porous Bronze on Motor |
| Brand | Dayton |
| Country of Origin (subject to change) | Mexico |
| Current Stock | 75 |
| Dimension A | 4.31 in |
| Dimension B | 1.17 in |
| Enclosure | Open |
| Full Load Amps | 1.4, 1.40 |
| Full Load Torque (In.-Lbs.) | 5.0 |
| Gear Case | Zinc Die Cast |
| Gear Case Material | Die Cast Zinc |
| Gear Ratio | 16:1, 15.6:1 |
| Gear Type | Spur |
| Gearmotor Brake Type | None |
| Gearmotor Enclosure | Open |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Phase | 1 |
| Gearmotor Rotation | CW |
| Gearmotor Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type | AC Gearmotor |
| Gearmotor Voltage | 115V AC, 115 V AC |
| Gears | All Spur Gears |
| Housing | Die Cast Zinc |
| Hz | 60, 60/50 Hz |
| Includes | Cooling Fan and Spring Clip |
| Input HP | 1/43 hp, 1/43 |
| Insulation Class | A |
| International Shipping | No |
| Item | AC Gearmotor |
| Length Less Shaft | 4-7/8", 4 7/8 in |
| Length Less Shaft (In.) | 4-7/8 |
| Lubrication | Grease, Grease filled |
| Max. Ambient Temp. | 40 Degrees C, 40 Degrees C |
| Max. Torque | 5.0 in-lb, 5 in.- lbs. |
| Motor Type | Shaded pole |
| Mounting | All Position |
| Mpn | 1MBG6 |
| Nameplate RPM | 214 RPM, 214 |
| No Load RPM | 227, 227 RPM |
| Overhung Load | 2 lbs., 2 lb |
| Overhung Load (Lb.) | 2 |
| Phase | 1 |
| Rotation | CW |
| RPM Range | 201 to 250 |
| Seals | Gasketed Gear Case |
| Shaft Dia. (Dimension U) | 5/16" |
| Shaft Dimensions (In.) | 5/16 x 3/4 |
| Shaft Length (Dimension V) | .75", 0.75" |
| Shaft Orientation | Parallel |
| Ship Weight | 5 lbs. |
| SKU | ZO-G1580241 |
| Standards | UL/CSA/CE |
| SubCategory | Power Transmission |
| Thermal Protection | Auto |
| Type | Parallel Shaft |
| UPC | 190735146422 |
| Voltage | 115 |
| Voltage Rating | 115 |
