mpn:
brand:
manufacturer:
MPN:
Weight:
10.0
Weight:
9.0 LB
Preferred Price:
516.16
Price:
516.16
Min Simple Price:
291.62
Absolute Min Price:
414.1
Min Price:
414.1
Dimensions:
[13.0, 6.0, 6.0]
qty:
21
simpleSku:
MTI3MQ:::2H563
sku:
MTI3MQ::74:2H563@y0
condition:
11
seller:
NRI Industrial
amzMan:
dayton
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Ambient (C) | 40 |
| Application | Conveyors, Roasters Packaging Equipment |
| Bearings | Needle Throughout, Ball on Motor |
| Brand | Dayton |
| Brushes | Externally Replaceable |
| Current Stock | 97 |
| Dimension D | 3.15 in |
| Dimension L | 8 39/50 in |
| Dimension X | 7.94" |
| Enclosure | TENV |
| Finish | Powder Coat Black |
| Full Load Amps | 1.08, 1.08 A, 1.22 A |
| Full Load Torque (In.-Lbs.) | 83.0 |
| Gear Case, Housing Material | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Gear Ratio | 25:1 |
| Gear Type, Gears | Hardened Steel, 1st Stage Helical, Subsequent Stages Spur |
| Gearmotor Enclosure | Totally Enclosed Nonventilated |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Shaft Orientation, Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type, Item | DC Gearmotor |
| Gearmotor Voltage | 90V DC, 90 V DC |
| Input HP | 1/10 |
| Insulation Class | F |
| International Shipping, Reversible Shaft Output | No |
| Keyway Size Type | 0.125 x 0.75 Long |
| Length Less Shaft | 8.75 in, 8-3/4" |
| Length Less Shaft (In.) | 8-3/4 |
| Lubrication | Permanent Heavy Fluid Gear Oil |
| Max. Ambient Temp. | 40 Degrees C |
| Max. Torque | 83 in-lb, 83 in.-lb. |
| Motor Type | Permanent Magnet DC |
| Mounting | All Position |
| Mpn | 2H563 |
| Nameplate RPM | 71 RPM, 71 |
| Output Shaft Diameter, Shaft Dia. (Dimension U) | 1/2 in |
| Output Shaft Length | 1 in |
| Overall Length | 9-3/4", 9.75 in |
| Overhung Load | 230 lbs. |
| Overhung Load (Lb.) | 230 |
| Phase | DC |
| Rear Shaft Encoder/Pulse Generator Mounting | Yes |
| Replacement Brushes | DTN6YHY6, 6YHY6 |
| Rotation | Reversible |
| Seals | Spring Loaded Lip Type on Input and Output Shaft |
| Shaft Dia. (Dimension U) | 1/2" |
| Shaft Dimensions (In.) | 1/2 x 1 |
| Shaft Length (Dimension V) | 1" |
| Ship Weight | 9 lbs. |
| SKU | ZO-G2119634 |
| Standards | C-UL Recognized, UL Recognized, cRUus, CSA, RoHS |
| SubCategory | Power Transmission |
| Thermal Protection | None |
| Type | Parallel Shaft |
| UPC | 190735219249 |
| Voltage Rating | 90VDC |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | NRI Industrial | D695203 | 291.62 | 291.62 | 1 | In Stock | DAYTON | 291.62 @ Qty: 1+ | ||
 | Zoro | G2119634 | 408.99 | 408.99 | 1 | 261 | Dayton | 8.7 | 408.99 @ Qty: 1+ | |
 | simsupply.com | ZO-G2119634 | 447.4 | 447.4 | 1 | 97 | Dayton | 447.4 @ Qty: 1+ | ||
| AmazonTP | B000TKCN74 | 463.59 | 463.59 | 1 | In Stock | 5 | Dayton Electric Manufacturing Co. | 463.59 @ Qty: 1+ | ||
 | sustainablesupply.com | C1672325 | 508.22 | 508.22 | 1 | In Stock | Dayton | 8.7 | 508.22 @ Qty: 1+ | |
| grainger.ca | DTN2H563 | 548.23030404 | 548.23030404 | 1 | In Stock | DAYTON | 8.71 | 548.23030404 @ Qty: 1+ | ||
| emotorpro.com | 2H563 | 552.12 | 552.12 | 1 | In Stock | Dayton | 9.0 | 552.12 @ Qty: 1+ | ||
 | Raptor Supplies | AB9ZTV | 670.9128075 | 670.9128075 | 1 | In Stock | DAYTON | 670.9128075 @ Qty: 1+ |
