| Bearings | Needle Throughout, Ball on Motor |
| Brake | Adaptable to 5X400 |
| Country of Origin (subject to change) | United States |
| Enclosure, Gearmotor Enclosure | Open |
| Full Load Amps | 1.05 |
| Gear Case Material, Housing | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Gear Ratio | 25:1 |
| Gear Type | Helical First Stage/Subsequent Stages Spur |
| Gearmotor Brake Type, Thermal Protection | None |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Phase, Phase | 1 |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Shaft Orientation, Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type, Item | AC Gearmotor |
| Gearmotor Voltage | 115V AC |
| Gears | Hardened Steel, 1st Stage Helical, Subsequent Stages Spur |
| Hz | 60 Hz |
| Input HP | 1/10 hp |
| Length Less Shaft | 7 1/2 in |
| Lubrication | Permanent Heavy Fluid Gear Oil |
| Max. Ambient Temp. | 40 Degrees C |
| Max. Torque | 90.0 in-lb |
| Motor Type | PSC |
| Mounting | All Position |
| Nameplate RPM | 63 RPM |
| Overhung Load | 230 lb |
| Rotation | Reversible |
| RPM Range | 51 to 75 |
| Seals | Spring Loaded Lip Type on Input and Output Shaft |
| Shaft Dia. (Dimension U) | 1/2" |
| Shaft Length (Dimension V) | 1" |
| Standards | UL Recognized, C-UL Recognized |
| Voltage | 115 |
