mpn:
brand:
manufacturer:
MPN:
Weight:
1.625
Weight:
14.0 LB
Preferred Price:
1429.48
Price:
1429.48
Min Simple Price:
807.62
Absolute Min Price:
1146.82
Min Price:
1146.82
Dimensions:
[20.0, 10.0, 9.0]
qty:
21
simpleSku:
MTI3MQ:::2H606
sku:
MTI3MQ::S4:2H606@y0
condition:
11
seller:
Zoro
amzMan:
dayton
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Ambient (C) | 40 |
| Bearings | Needle Throughout with Thrust Balls on Case, Ball on Motor |
| Brand | Dayton |
| Capacitor Required | Included |
| Country of Origin (subject to change) | United States |
| Current Stock | 8 |
| Dimension A | 5.2/2.8 in |
| Dimension D1 | 5.61" |
| Dimension D2 | 6.76" |
| Dimension L | 15.1" |
| Enclosure | TEFC |
| Full Load Amps | 5.2/2.8 |
| Full Load Torque (In.-Lbs.) | 345.0 |
| Gear Case, Gear Case Material, Housing | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Gear Ratio | 20:1 |
| Gear Type | Helical First Stage/Subsequent Stages Spur/AGMA Class 9 |
| Gearmotor Brake Type, Thermal Protection | None |
| Gearmotor Enclosure | Totally Enclosed Fan-Cooled |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Phase, Phase | 1 |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Shaft Orientation, Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type, Item | AC Gearmotor |
| Gearmotor Voltage | 115/230V AC, 115/230 V AC |
| Gears | Hardened Steel, 1st Stage Helical, Subsequent Stages Spur, AGMA Class 9 |
| Hz | 60/50 Hz, 50/60, 60/50 |
| Input HP | 1/2 hp, 1/2 |
| International Shipping | No |
| Length Less Shaft | 16", 16 in |
| Length Less Shaft (In.) | 16 |
| Lubrication | Permanent Heavy Fluid Gear Oil |
| Max. Ambient Temp. | 40 Degrees C, 40 Degrees C |
| Max. Torque | 345 in.- lbs., 345.0 in-lb |
| Motor Type | PSC, Permanent Split Capacitor |
| Mounting | All Position |
| Mpn | 2H606 |
| Nameplate RPM | 81 RPM, 81 |
| Overhung Load | 550 lb, 550 lbs. |
| Overhung Load (Lb.) | 550 |
| Rotation | Reversible, Rev. |
| RPM Range | 76 to 100 |
| Seals | Spring Loaded Lip Type on Input and Output Shaft |
| Shaft Dia. (Dimension U) | 3/4" |
| Shaft Dimensions (In.) | 3/4 x 1 7/8 |
| Shaft Length (Dimension V) | 1.88", 1.88: |
| Ship Weight | 26 lbs. |
| SKU | ZO-G2306376 |
| Standards | UL Recognized, CSA Certified |
| SubCategory | Power Transmission |
| Type | Parallel Shaft |
| UPC | 190735219423 |
| Voltage, Voltage Rating | 115/230 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G2306376 | 807.62 | 807.62 | 1 | In Stock | Dayton | 26.0 | 807.62 @ Qty: 1+ | |
 | simsupply.com | ZO-G2306376 | 937.31 | 937.31 | 1 | 8 | Dayton | 937.31 @ Qty: 1+ | ||
 | sustainablesupply.com | C1672342 | 980.06 | 980.06 | 1 | In Stock | Dayton | 26.0 | 980.06 @ Qty: 1+ | |
| emotorpro.com | 2H606 | 987.5 | 987.5 | 1 | In Stock | Dayton | 26.0 | 987.5 @ Qty: 1+ | ||
| grainger.ca | DTN2H606 | 1060.2211145 | 1060.2211145 | 1 | In Stock | DAYTON | 26.0 | 1060.2211145 @ Qty: 1+ | ||
 | Raptor Supplies | AB9ZUP | 1235.0404755 | 1235.0404755 | 1 | In Stock | DAYTON | 1235.0404755 @ Qty: 1+ |
