Amps | 0.24 |
Bearings | Ball |
Blade Material | Polybutylene |
CFM @ 0.000-In. SP | 200 |
Country of Origin (subject to change) | China |
dBA, Fan dBA | 55 |
Depth, Fan Depth | 2" |
Electrical Connection - Fans | 12 in Leads |
Electrical Connection - Fans, Electrical Connections | 12" Leads |
Fan Width, Fan Width, Height | 6-3/4" |
Fan Height, Width | 5-15/16" |
Fan Item, Item | Axial Fan |
Fan RPM | 2950 |
Fan Shape | Oblong |
Fan Shape, Shape | Round |
Fan Voltage, Voltage | 230VAC |
Fan Watts, Watts | 36 |
Housing Finish | Black |
Housing Material | Aluminum |
Hz | 60/50 |
Max. Ambient Temp. | 158 Degrees F, 158 Degrees F |
Motor Insulation | Class A |
Motor Type | Shaded pole |
Mounting Eye O.C., Mounting Eye O.C. - Fans | 6-3/8" |
Mounting Position | Vertical or Horizontal |
Phase | 1 |
Requires | - |
Standards | UL Component Recognized for US and Canada, CE Certified and RoHS Compliant |
Thermal Protection | Impedance |
Voltage | 230 |
