mpn:
brand:
manufacturer:
MPN:
Weight:
96.0
Weight:
6.0 LB
Preferred Price:
877.83
Price:
877.83
Min Simple Price:
495.95
Absolute Min Price:
704.24
Min Price:
704.24
Dimensions:
[21.0, 17.0, 13.0]
qty:
21
simpleSku:
ODEwOA:::36VF22
sku:
ODEwOA::QX:36VF22@y0
condition:
11
seller:
AmazonTP
amzMan:
cai - dayton
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| Amps | 8.4-7.6/3.8 |
| Bearings | Ball |
| Brand | Dayton |
| Capacitor Required | No |
| CC Number | CC029A |
| Color | Black |
| Country of Origin (subject to change) | Mexico |
| Current Stock | 22 |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Enclosure Material | Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Footnotes | 2, 15, 55 |
| Frame | 182/4TC |
| Frame Material | Rolled Steel |
| Full Load Amps | 7.6/3.8 |
| Green Certification or Other Recognition | NEMA Premium Rated |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| HP | 3 |
| Hz | 60 |
| Includes | Conduit Box |
| Ins. Class | F |
| Insulation Class | F |
| International Shipping | No |
| Inverter Rated | Yes |
| Item | General Purpose Motor |
| Lead Time | Expected to ship in 1-2 business days |
| Length Less Shaft | 15 3/16 in |
| Manufacturers Warranty Length | 1 yr |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face/Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Shell Length | 15-5/32" |
| Motor Thermal Protection | None |
| Mounting | C-Face/Rigid |
| Mpn | 36VF22 |
| Nameplate RPM | 1,765 |
| No. of Speeds | 1 |
| Nominal Efficiency | 89.5 % |
| Number of Speeds | 1 |
| Overall Length | 17-15/16", 17 15/16 in |
| Phase | 3, Three |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 1765 |
| RPM Group | 1701-1800 |
| RPM Range | 1,701-1,800 |
| Service Factor (SF) | 1.15 |
| Shaft Dia. | 1 1/8 in |
| Shaft Diameter | 1-1/8" Keyed |
| Shaft Length | 2-3/4", 2 3/4 in |
| Ship Weight | 96 lbs. |
| SKU | ZO-G0692231 |
| Standards | CE, CSA, UL |
| SubCategory | Motors/Ac Motors |
| Thermal Protection | None |
| UPC | 190735275542 |
| Voltage | 230/460V AC |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC |
| Volts | 208-230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| AmazonTP | B0716K3YHN | 495.95 | 495.95 | 1 | In Stock | 5 | DAYTON | 495.95 @ Qty: 1+ | ||
 | Zoro | G0692231 | 553.97 | 553.97 | 1 | In Stock | Dayton | 96.0 | 553.97 @ Qty: 1+ | |
| emotorpro.com | 36VF22 | 783.29 | 783.29 | 1 | In Stock | Dayton | 96.0 | 783.29 @ Qty: 1+ | ||
 | simsupply.com | ZO-G0692231 | 823.7 | 823.7 | 1 | 22 | Dayton | 823.7 @ Qty: 1+ | ||
 | Raptor Supplies | AH7KML | 1039.5265725 | 1039.5265725 | 1 | In Stock | DAYTON | 1039.5265725 @ Qty: 1+ |
