mpn:
brand:
manufacturer:
MPN:
Weight:
36.0
Weight:
2.25 LB
Preferred Price:
548.42
Price:
548.42
Min Simple Price:
309.85
Absolute Min Price:
439.98
Min Price:
439.98
Dimensions:
[16.0, 13.0, 10.0]
qty:
21
simpleSku:
ODEwOA:::36VF88
sku:
ODEwOA::GW:36VF88@y0
condition:
11
seller:
AmazonTP
amzMan:
cai - dayton
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| Amps | 4.9-4.4/2.2 |
| Bearings, Motor Bearings | Ball |
| Brand | Dayton |
| CC Number | CC029A |
| Color | Black |
| Current Stock | 47 |
| Duty Cycle | Continuous |
| Efficiency | 86.5% |
| Enclosure Material | Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Environmental Claim, Motor Thermal Protection, Thermal Protection | None |
| Frame | 56C |
| Full Load Amps | 4.4/2.2 |
| Green Certification or Other Recognition | NEMA Premium(R) Rated |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| HP | 1 1/2, 1-1/2 |
| Hz | 60 |
| Ins. Class, Insulation Class | F |
| International Shipping | No |
| Inverter Rated | Yes |
| Item | General Purpose Motor |
| Length Less Shaft | 11 1/4 in |
| Manufacturers Warranty Length | 1 yr |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Design | 3-Phase |
| Motor Diameter | 6-1/2" |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face/Base |
| Motor Service Factor, Service Factor (SF) | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Shell Length | 11-1/4" |
| Motor Thermal Protection | Not Applicable |
| Mounting | C-Face/Rigid |
| Mpn | 36VF88 |
| Nameplate RPM | 1,750 |
| No. of Speeds, Number of Speeds | 1 |
| Nominal Efficiency | 86.5 % |
| Overall Length | 13 1/8 in, 13-1/8" |
| Phase | 3, Three |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 1750 |
| RPM Group | 1701-1800 |
| RPM Range | 1,701-1,800 |
| Shaft Dia. | 5/8 in |
| Shaft Diameter | 5/8" Keyed |
| Shaft Length | 1-7/8", 1 7/8 in |
| Ship Weight | 36 lbs. |
| SKU | ZO-G0691951 |
| Standards | CE, CSA, UL |
| SubCategory | Motors/Ac Motors |
| UPC | 190735276204 |
| Voltage | 230/460V AC |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC |
| Volts | 208-230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| AmazonTP | B072KCKQNJ | 309.85 | 309.85 | 1 | In Stock | 2 | DAYTON | 309.85 @ Qty: 1+ | ||
 | Zoro | G0691951 | 378.99 | 378.99 | 1 | 68 | Dayton | 35.3 | 378.99 @ Qty: 1+ | |
| grainger.ca | WWG36VF88 | 425.11909032 | 425.11909032 | 1 | In Stock | DAYTON | 35.3 | 425.11909032 @ Qty: 1+ | ||
 | simsupply.com | ZO-G0691951 | 448.59 | 448.59 | 1 | 47 | Dayton | 448.59 @ Qty: 1+ | ||
| emotorpro.com | 36VF88 | 498.46 | 498.46 | 1 | In Stock | Dayton | 36.0 | 498.46 @ Qty: 1+ | ||
 | sustainablesupply.com | C2777249 | 577.61 | 577.61 | 1 | In Stock | Dayton | 35.3 | 577.61 @ Qty: 1+ | |
 | Raptor Supplies | AH7KQD | 622.6432875 | 622.6432875 | 1 | In Stock | DAYTON | 622.6432875 @ Qty: 1+ |
