| Body Dia. | 4 7/16 in |
| Capacitor Required, Usable @ 200V, Usable @ 208V | No |
| Country of Origin (subject to change) | Mexico |
| Duty, Duty Cycle | Continuous |
| Frame | 4.4 |
| Full Load Amps | 3.3 |
| HP | 1/10 |
| Hz | 60 Hz |
| Includes | 5 cu. in. Junction Box |
| Ins. Class | B |
| Item | HVAC Motor |
| Length Less Shaft | 5 3/8 in |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | HVAC/R |
| Motor Bearings | Sleeve |
| Motor Design | Shaded Pole |
| Motor Enclosure Design | Open |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Stud |
| Motor Service Factor, No. of Speeds, Number of Shafts | 1 |
| Motor Shaft Rotation | CWSE |
| Motor Sub Application | Direct Drive Fan/Blower |
| Motor Thermal Protection | Auto |
| Mounting Stud Pattern | 2 3/4 in x 2 3/4 in |
| Nameplate RPM | 1,550 RPM |
| Phase | Single |
| RPM Range | 1,501-1,600 |
| Shaft Dia. | 3/8 in |
| Shaft Length | 2 in |
| Standards | CSA (701887), UL (E37403) |
| Stud/Base Mtg. Pattern | 2-3/4 in x 2-3/4 in |
| Voltage | 115V AC |
| Voltage Compatibility | 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC |
