mpn:
brand:
manufacturer:
MPN:
Weight:
29.0
Weight:
29.0 LB
Preferred Price:
1233.67
Price:
1233.67
Min Simple Price:
696.99
Absolute Min Price:
989.72
Min Price:
989.72
Dimensions:
[20.0, 10.0, 9.0]
qty:
21
simpleSku:
Dk0NzU:::6K375
sku:
Dk0NzU::EM:6K375@y0
condition:
11
seller:
Zoro
amzMan:
dayton
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Ambient (C) | 40 |
| Application | Conveyors, Packaging Equipment |
| Bearings | Heavy Duty Needle Roller and Thrust Balls on Case, Ball on Motor, Heavy Duty Ball, Needle Roller and Thrust Balls on Case, Ball on Motor |
| Brake | 4Z447 |
| Brand | Dayton |
| Current Stock | 8 |
| Enclosure | TEFC |
| Finish | Powder Coat Black |
| Full Load Amps | 7.80 A, 7.80 |
| Full Load Torque (In.-Lbs.) | 700.0 |
| Gear Case, Gear Case Material, Housing | Die Cast Aluminum |
| Gear Material | Hardened Steel |
| Gear Ratio | 43:1 |
| Gear Type | Helical First Stage/Subsequent Stages Spur/AGMA Class 9 |
| Gearmotor Brake Type, Thermal Protection | None |
| Gearmotor Enclosure | Totally Enclosed Fan-Cooled |
| Gearmotor Mounting Position | All Angle |
| Gearmotor Phase, Phase | 1 |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Shaft Orientation, Shaft Orientation | Parallel |
| Gearmotor Shaft Type | Single |
| Gearmotor Type, Item | AC Gearmotor |
| Gearmotor Voltage | 115V AC, 115 V AC |
| Gears | Hardened Steel, 1st Stage Helical, Subsequent Stages Spur, AGMA Class 9, Hardened Steel, 1 St Stage Helical, Subsequent Stages Spur, AGMA Class 9 |
| Hz | 60 |
| Input HP | 1/2 |
| Insulation Class | B |
| International Shipping | No |
| Keyway Depth | 0 in |
| Keyway Size Type | 3/16" x 1" |
| Keyway Width | 3/16 mm |
| Length Less Shaft | 12 3/4 in, 12-3/4" |
| Length Less Shaft (In.) | 12-3/4 |
| Lubrication | Permanent Heavy Duty Gear Oil |
| Max. Ambient Temp. | 40 Degrees C |
| Max. Torque | 700.0 in-lb, 700 in.-lb. |
| Motor Type | Split-phase |
| Mount Hole Center-to-Center Length | 2.5 in |
| Mount Hole Center-to-Center Width | 7.13 in |
| Mounting | All Position |
| Mpn | 6K375 |
| Nameplate RPM | 41 RPM, 41 |
| Output Shaft Diameter, Shaft Dia. (Dimension U) | 3/4 in |
| Output Shaft Height | 3 in |
| Output Shaft Length | 1 1/2 in |
| Overall Height | 6.63 in |
| Overall Width | 8.13 in |
| Overhung Load | 325 lbs. |
| Overhung Load (Lb.) | 325 |
| Rotation | Rev. |
| Seals | Lip Type on Input and Output Shaft |
| Shaft Dia. (Dimension U) | 3/4" |
| Shaft Dimensions (In.) | 3/4 x 1 1/2 |
| Shaft Length (Dimension V) | 1.5", 1.5 in_x000D_ |
| Ship Weight | 30 lbs. |
| SKU | ZO-G0305033 |
| Standards | UL |
| SubCategory | Power Transmission |
| Type | Parallel Shaft |
| UPC | 190735365793 |
| Voltage Rating | 115 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G0305033 | 696.99 | 696.99 | 1 | 1 | Dayton | 29.75 | 696.99 @ Qty: 1+ | |
 | simsupply.com | ZO-G0305033 | 824.89 | 824.89 | 1 | 8 | Dayton | 824.89 @ Qty: 1+ | ||
 | sustainablesupply.com | C1698094 | 890.86 | 890.86 | 1 | In Stock | Dayton | 29.75 | 890.86 @ Qty: 1+ | |
| emotorpro.com | 6K375 | 942.5 | 942.5 | 1 | In Stock | Dayton | 30.0 | 942.5 @ Qty: 1+ | ||
| grainger.ca | DTN6K375 | 1081.90093972 | 1081.90093972 | 1 | In Stock | DAYTON | 30.2 | 1081.90093972 @ Qty: 1+ | ||
 | Raptor Supplies | AE9JGM | 1144.479258 | 1144.479258 | 1 | In Stock | DAYTON | 1144.479258 @ Qty: 1+ |
