| Bar Style | J-Hook |
| Base Length (Decimal Inch), Width Distance Between Mount Holes (Decimal Inch) | 1.9400 |
| Base Length (mm), Width Distance Between Mount Holes (mm) | 49.28 |
| Base Style | Flanged |
| Base to Center of Bar (Decimal Inch) | 1.4200 |
| Base to Center of Bar (mm) | 36.07 |
| Base Width (Decimal Inch) | 2.6300 |
| Base Width (mm) | 66.80 |
| Clamping Orientation | Horizontal |
| Drawing Movement (Decimal Inch) | 5.380 |
| Drawing Movement (mm) | 136.65 |
| Handle Color | Red |
| Handle Style | Straight |
| Length Distance Between Mount Holes (Decimal Inch) | 1.2500 |
| Length Distance Between Mount Holes (mm) | 31.75 |
| Load Capacity (Lb.) | 751 |
| Load Capacity (N) | 3340.00 |
| Material | Carbon Steel |
| Mounting Hole Diameter (Decimal Inch) | 0.3400 |
| Mounting Hole Diameter (mm) | 8.64 |
| Overall Height (Decimal Inch) | 2.6500 |
| Overall Height (mm) | 67.31 |
| Overall Length (Decimal Inch) | 16.6771 |
| Overall Length (mm) | 423.60 |
