Key | Value |
---|---|
Application | Liquid |
Basic Pipe Fitting Material | Metal |
Brand | Dixon Valve & Coupling |
Clean Bagged | No |
Construction | Buna-N Gasket |
Coupling Type | Type DC |
Description: | 1" 316SS Dust Cap |
Diameter - Outside | 1-7/8 in |
Domestic/Import | Domestic |
Fitting Size 1 | 1 in |
Fitting Sizes | 1 in |
Fitting/Connector Type | Cap |
FM Approved | No |
Height | 2-3/16 in |
IAPMO Listed - | No |
Item | Cam and Groove Type DC Dust Cap SS,1" |
Length | 2-3/16 in |
Manufacturer | Dixon Valve & Coupling Co |
Material | Stainless Steel, 316 Stainless Steel |
Material Type | 316 |
MFG Part #: | 100-DC-SS |
MPN | 100-DC-SS |
Nominal Size | 1 in |
Note | Finger rings are NOT supplied |
NSF Certified | No |
Options | Other gasket types are available, Contact Anderson Process. |
Package Quantity | 1 |
Pipe Fitting Material | 316 Stainless Steel |
Product | Dust Cap |
Product Type | Simple product |
Safety Notes | Dust caps and dust plugs are not to be used in pressure applications for safety and environmental reasons. |
Seal | Nitrile rubber, Buna-N |
Series | Dixon? |
Size | 1 in, 1" |
Specifications | Produced to interchange with all product produced to Commercial Item Description A-A-59326D. |
Supplier: | Dixon Valve & Coupling Co |
Type | Type DC |
UL Listed | No |
WARNING! | This product contains a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling. For more information go to www.P65Warnings.ca.gov |
Weight | 0.6 lb, 0.600000 |
Weight Lb | 0.6000 |
Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
---|---|---|---|---|---|---|---|---|---|---|
![]() ![]() | toolfetch.com | DIX-100-DC-SS | 39.49 | 110.572 | 1 | 4 | DIXON VALVE | 39.49 @ Qty: 4+ | ||
![]() ![]() | Amazon | B007YZFLO4 | 41.77 | 116.956 | 1 | 4 | Dixon | 41.77 @ Qty: 4+ | ||
![]() ![]() | andersonprocess.com | 100-DC-SS | 43.66 | 122.248 | 1 | 4 | 26 | Dixon Valve & Coupling | 0.6 | 43.66 @ Qty: 4+ |
![]() ![]() | usmegastore.com | 100-DC-SS | 46.7 | 130.76 | 1 | 4 | Dixon Valve | 0.6 | 46.7 @ Qty: 4+ | |
![]() ![]() | Megadepot | 100-DC-SS | 46.7 | 130.76 | 1 | 4 | Dixon Valve | 0.6 | 46.7 @ Qty: 4+ | |
![]() ![]() | heavydutydepot.com | 100-DC-SS | 46.7 | 168.12 | 3 | 4 | Dixon | 46.7 @ Qty: 4+ | ||
kscdirect.com | DIX 100-DC-SS | 47.83 | 133.924 | 1 | 4 | Dixon Valve & Coupling Co | 47.83 @ Qty: 4+ | |||
![]() ![]() | MRO Supply | 102428 | 50.55 | 141.54 | 1 | 4 | Dixon | 50.55 @ Qty: 4+ | ||
![]() ![]() | Zoro | G6551800 | 51.79 | 145.012 | 1 | 4 | Dixon Valve & Coupling | 0.05 | 51.79 @ Qty: 4+ | |
Turner Supply | 746430100 | 56.17 | 157.276 | 1 | 4 | Dixon Valve & Coupling | 56.17 @ Qty: 4+ | |||
![]() ![]() | industrialzone.com | 100-DC-SS | 61.71 | 246.84 | 4 | 4 | Dixon | 0.6 | 61.71 @ Qty: 4+ | |
![]() ![]() | directools.com | 100-DC-SS | 65.72 | 184.016 | 1 | 4 | Dixon | 65.72 @ Qty: 4+ | ||
ferguson.com | 367487 | 71.52 | 200.256 | 1 | 4 | Dixon Valve & Coupling | 0.6 | 71.52 @ Qty: 4+ | ||
motionindustries.com | 01628232 | 76.87 | 215.236 | 1 | 4 | Dixon Valve & Coupling Company, LLC | 76.87 @ Qty: 4+ | |||
![]() ![]() | National Supply Network | 79312971 | 114.7875 | 321.405 | 1 | 4 | Dixon Valve & Coupling | 114.7875 @ Qty: 4+ | ||
![]() ![]() | Wilson | 100-DC-SS | 140.34 | 392.952 | 1 | 4 | Dixon | 140.34 @ Qty: 4+ |
