3STF3-SS DIXON VALVE & COUPLING | Search our online catalog of Hose and Fittings. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key ^ | Value |
|---|---|
| Available options | Contact Dixon for all available option adders; Standard seal options include: FKM, EPDM, Mil-Nitrile and Fuel Nitrile; Kalrez? seal options include: 4079, 6375 and 7075; Oxy-clean treatment is available |
| Body size | 3/8" |
| Burst Pressure | 28000 PSI (1900 bar) |
| Compatibility & interchange data | Interchangeable with Snap-Tite 71-Series |
| Domain | GBR; DNK; SWE; IRL; NOR; FIN; ARE; USA; AUS; CHN; IND; SGP; CAN |
| Hex | 1-3/16" |
| Length | 2.36" |
| Length (metric) | 59.9mm |
| Material | 316 Stainless Steel |
| Maximum od | 1.6" |
| Maximum od (metric) | 40.6mm |
| Maximum operating pressure | 5000 PSI (345 bar) |
| Safety notes | WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov |
| Temperature range | -40?F to +250?F |
| Temperature range (metric) | -40?C to +121?C |
| Thread | Female NPTF |
| Thread Size | 3/8"-18 |
| Weight lb | 0.38 |
