Description:
HT8F10-SS DIXON VALVE & COUPLING | Search our online catalog of Hose and Fittings. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key ^ | Value |
|---|---|
| Available options | Contact Dixon for all available option adders; Oxy-Clean treatment is available |
| Body size | 1" |
| Compatibility & interchange data | Interchangeable to ISO16028; Conforms to ISO16028 interchange standard interchangeable with Eaton/Hansen FF, Parker FEM, Snap-tite 74, Faster FFH/2FFN/2FFI, Stucchi A/FIRG and Holmbury HQ/A/FIMC |
| Domain | ARE; FIN; DNK; NOR; IRL; SWE; GBR; CAN; SGP; CHN; AUS; USA |
| Hex | 2" |
| Length | 3.61" |
| Length (metric) | 91.7mm |
| Material | 316 Stainless Steel |
| Maximum od | 2.19" |
| Maximum od (metric) | 55.6mm |
| Pressure rating | See Product Details |
| Safety notes | WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov |
| Specifications | Rated pressure for connected 316 Stainless Steel Coupler and 316 Stainless Steel Plug: 2,920 PSI (201 bar) Maximum Working and 14,600 PSI (1,007 bar) burst |
| Thread | Female NPTF |
| Thread Size | 1-1/4" - 11-1/2 |
| Weight lb | 1.84 |
