Dodge F4B-SC-107-NL

B00RW7CZIO

Dodge Baldor F4B-SC-107-NL 050835 4-Bolt Set Screw Flange Block 1-7/16

Dodge Baldor F4B-SC-107-NL 050835 4-Bolt Set Screw Flange Block 1-7/16zoom

Attributes

Key Value
ApplicationGeneral Purpose
Ball bearing series207 series
Bearing typeBall, ball
Bolt Diameter0.5000 in
Bolt Spacing3.625 Inch | 92.08 Mill.
Bolt to bolt max3.6300 in, 92.202 mm
Bolt to bolt min3.6300 in, 92.202 mm
Bore1 7/16 in, 1.438 Inch |.
Bore length1.7100 in, 43.434 mm
BrandDODGE
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
CategoryFlange Block Bearings
DutyStandard Duty
EAN0782475863044
ExpansionNo
Expansion / Non-expansi.Non-expansion
Expansion capabilityNon-expansion (fixed)
Global Part Number GPN549826
GreasableNo
Harmonized Tariff Code8483.20.40.40
High tempNo
HousingCast Iron
Housing Configuration1 Piece Solid
Housing constructionSolid
Housing MaterialCast Iron
Housing materialCast Iron
Housing optionCast Iron
Housing Style4 Bolt Square Flange Bl.
Housing typeFour-bolt flange
I.D.1 1/5 in
Inch - MetricInch
Insert materialSteel
Insert optionBearing steel
Insert Part NumberINS-SC-107
Insert typeBall Bearing
Length Thru Bore1.531 Inch | 38.9 Milli.
LockingSet Screw
Lubrication typeGrease
Manufacturer NameABB MOTORS AND MECHANIC.
Max Speed3500 RPM
Mounting Bolts1/2 Inch
Mounting MethodSet Screw
Nominal Bolt Circle Dia.5.1 Inch | 130 Millimet.
Number of Mounting Holes4
Other FeaturesSingle Row | Normal Dut.
Pilot ConfigurationNo Pilot
price$ 95.57 / each
RelubricatableNo
RelubricationNo
Rolling elementStandard duty ball
Seal optionDualGuard seals with fl.
SealsSingle Lip Contact
Sensor readyAdapter required
Shaft attachmentSetscrew
Shaft diameter1.4375 in
Standoff housingNo
Static load capacity3461 lbf, 15395.295 N
Suitable for high tempe.No
Suitable for washdownNo
titleF4B-SC-107-NL
Type4-bolt flange
UNSPSC31171501
Weight / kgm1.56
Weight / LBS3.7

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomLily BearingF4B-SC-107-NL81.231In StockDODGE3.43281.23 @ 1
thumbzoomMRO Supply131769102.481In StockDodge102.48 @ 1
thumbzoomapexindustrialautomation.comF4B-SC-107-NL103.861In StockDodge103.86 @ 1
motionindustries.com03189326160.491In StockDodge160.49 @ 1
