| Accuracy | +/-0.5% |
| Accuracy Grade | ASME B40.100 Grade 2A |
| Accuracy Scale | Full Scale |
| Ambient Operating Temperature Range, Operating Temp. Range | -30 Degrees to 250 Degrees F |
| Bezel Mounting Type | Threaded |
| Blowout Safety Back, Calibration Certificate Included, Cleaned for Oxygen Service, Field Fillable, Freeze Resistant Movement, Includes Calibration Certificate, Includes Mounting Hardware, Includes Vent Plug, Liquid Filled, Liquid-Filled Case, Non-Sparking | No |
| Case Color, Gauge Case Color | Black |
| Case Construction | Corrosion Resistant |
| Case Depth | 2.32 in |
| Case Diameter | 6.56 in |
| Connection Location, Gauge Connection Location, Process Connection Location | Bottom |
| Connection Size | 1/4 in NPT |
| Country of Origin (subject to change) | United States |
| Dial Color | White |
| Dial Face Material, Gauge Case Material | Aluminum |
| Dry Dampening Feature, Gauge Case Liquid, Vibration Resistance | None |
| For Use With | Media Compatible with 316L Stainless Steel |
| Gauge Accuracy | +/-0.50% |
| Gauge Accuracy Grade | Grade 2A - Process |
| Gauge Connection Size, Process Connection Size | 1/4 in |
| Gauge Connection Type | MNPT |
| Gauge Lens Material, Lens Material, Lens Material - Gauge | Glass |
| Gauge Mounting Type | Back Flange |
| Gauge Nominal Dial Size, Nominal Dial Size | 6 in |
| Gauge Primary Range Numbered Graduations, Series | 20 |
| Gauge Primary Range Smallest Graduation | 10 |
| Gauge Primary Range Units, Primary Scale Units | psi |
| Gauge Primary Range Values, Primary Pressure Range | 0 to 300 |
| Gauge Secondary Range Units, Secondary Scale Units | Bar |
| Gauge Secondary Range Values | 0 to 10 |
| Gauge Sensor Material, Gauge Socket Material, Socket Material | 316 Stainless Steel |
| Gauge Wetted Parts, Movement Material, Sensor Material | Stainless Steel |
| Graduations, Smallest Graduation | 10 psi |
| Hazardous Location Rating, IP/NEMA Rating | Not Rated |
| Item, Pressure Gauge Type | Industrial Pressure Gauge |
| Manufacturer Warranty Length, Manufacturers Warranty Length | 1 yr |
| Movement Type | Rotary |
| Panel-Mountable, Removable Bezel | Yes |
| Pointer Characteristics | Lightweight Balanced Construction with Micrometer Adjustment |
| Pressure Range Type | Pressure |
| Primary Scale Minor Graduations | 2 |
| Process Connection Gender | Male |
| Process Connection Type | NPT |
| Range | 0 to 300 psi |
| Scale Type | Dual |
| Secondary Pressure Range | 0 to 21 |
| Sensor Type | Bourdon Tube |
