Dwyer I2-4B062
Dwyerzoom
brand:
manufacturer:
Description:
<p><strong>Dwyer, I2-4B062, Series I2-4 Weatherproof Immersion Temperature Sensor, 6", 10 kOhms Type III </strong> </p> <p>Twist Off Cover, Multiple Conduit Holes </p> <p><strong>The Series I2-4 Weatherproof Immersion Temperature Sensor </strong> is ideal for monitoring hot and chilled water lines feeding Air Handlers and Cooling Towers. The plastic housing has a 1/4 turn twist off cover to reduce installation time. The multiple knockouts allow for easy conduit access to any side of the housing. The Series I2-4 can be ordered with a choice of 11 output options that allow it to communicate to any standard building control system. </p> <p><strong>Note: </strong> A Series IW2 Thermowell must be used on pressurized air and water lines to prevent leakage around the probe. </p>

Attributes

Key Value
AccuracyPlatinum RTD: ?0.6% @ 32?F (0?C); Nickel RTD: ?0.5?F @ 32?F (0?C); Balco RTD: ?0.1% @ 32?F (0?C); Thermistors: ?0.36?F from 32 to 158?F (0 to 70?C)
Cable Length8"
Mounting1/2" threaded connection to fit IW2 Series Thermowell
Operating Temperature-32 to 240?F (-35.5 to 115.5?C)
Probe Diameter1/4" (6.3 mm)
Probe Material304 SS
