| Accuracy, Linearity | ?1% of full scale |
| Agency Approvals | CE |
| Display | LCD, 0.39" (10 mm) digits (only in LPM) |
| Electrical Connections | Four-pin power and signal connector. A power adapter or mating cable required for operation |
| Enclosure Rating | IP10 (NEMA 1) |
| Output Signal | 0 to 5 VDC; minimum 2.5 k ? load |
| Power Consumption | 35 mA @ 12 VDC |
| Power Requirements | 11.5 to 15 VDC |
| Pressure Limits | 500 psig (34.5 bar) |
| Repeatability | ?0.2% of full scale |
| Service | Clean liquids compatible with wetted materials |
| Temperature Limits | 41 to 131?F (5 to 55?C); Storage: 32 to 158?F (0 to 70?C); Sensitivity: ?0.2% of full scale per ?C |
| Weight | 0.80 lb (380 g) |
| Wetted Materials | 316 SS, acetal, sapphire, glass, epoxy, and fluoroelastomer |
