Eaton FAZ-C3/3

Technical Specification Item IEC Supplementary Protector Amps 3 AC Voltage Rating 277/480VAC Max. AIR Rating 15kA at 277/480VAC Series FAZ Curve Type C DC Voltage Rating 96VDC Number of Poles 3 Phase 3 Circuit Breaker Actuator Toggle Circuit Breaker Mounting Style DIN Rail Meets UL Type UL 1077 Terminal Connection Lug Trip Type Thermal Magnetic Application Industrial, Small Transformers, Lighting, Pilot Devices, Control Circuits and Coils; PLC Wiring, Business Equipment, Lighting, Appliances and Some Motors; Motors, Transformers and Power Supplies Min. Wire Size 18 AWG Max. Wire Size 4 AWG Length 2.07 Width 2 Depth 2.07 Standards CSA C22.2 No. 235, IEC 60947-2, UL 1077 Compliance and Restrictions Hazardous material - General This listing is for each.
