mpn:
brand:
manufacturer:
MPN:
Weight:
1.26
Weight:
0.165625 LB
Preferred Price:
909.12
Price:
909.12
Min Simple Price:
513.63
Absolute Min Price:
729.35
Min Price:
729.35
Dimensions:
[6.0, 5.0, 4.0]
qty:
21
simpleSku:
DI0NTc:::CN15DN3TB
sku:
DI0NTc::KN:CN15DN3TB@y0
condition:
11
seller:
turtle.com
amzMan:
eaton
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Action | Non-Reversing |
| Application | Commercial / Institutional Buildings / Structures - Commercial / Institutional Buildings / Structures - Other |
| Auxiliary Contact Form, Auxiliary Contacts | 1NO |
| Brand, Manufacturer | Eaton |
| Catalog Number, Item Number, Manufacturer Part Number, Part Number | CN15DN3TB |
| Coil Type | Magnetic |
| Coil Voltage, Nominal Coil Voltage | 24 VAC |
| Coil Volts | 24V AC |
| Country of Origin | United States |
| Country of Origin (subject to change) | Dominican Republic |
| Depth | 5.6 in |
| Enclosure NEMA Rating | No Enclosure |
| Family / Style, Product Series | Freedom |
| Family Series | Cutler Hammer, Div of Eaton Corp Contactors, FREEDOM Series |
| Frame / Series / Class / Code | Series Freedom, Code A, Frame 180mm |
| Full Load Amps | 27 A |
| Gross Weight | 1 lb |
| Height | 3.4 in |
| HP @ 1 Phase - 120V | 2 hp |
| HP @ 1 Phase - 240V | 3 hp |
| HP @ 3 Phase - 208V, HP @ 3 Phase - 240V | 7 1/2 hp |
| HP @ 3 Phase - 480V, HP @ 3 Phase - 575V | 10 hp |
| Hz | 50/60 |
| In Stock, Reversing | No |
| Item | Magnetic Contactor |
| Item Type | Motor control contactor |
| Made in USA | Yes |
| Manufacturer | Cutler Hammer, Div of Eaton Corp, Eaton Cutler Hammer |
| Max HP 115V 1PH | 2 Horsepower |
| Max HP 200/208V 3PH, Max HP 230/240V 3PH | 7.5 Horsepower |
| Max HP 230/240V 1PH | 3 Horsepower |
| Max HP 460/480V 3PH, Max HP 575/600V 3PH | 10 Horsepower |
| NEMA Contactor Size, NEMA Frame Size, NEMA Size, Phase, Size | 1 |
| NEMA Continuous Current (I) | 27 |
| Net Weight | 0 lbs |
| Number of Poles | 3 |
| Overload Relays | C306; C396 |
| Poles | 3NO |
| Standard | CSA Certified,UL Listed |
| Standards | CSA File Number LR353, UL File Number E1491 |
| Termination | Box Lug |
| Type | NEMA Contactor |
| UPC | 782113026794 |
| Width | 4.8 in |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | turtle.com | CUH CN15DN3TB | 513.63 | 513.63 | 1 | In Stock | Eaton | 513.63 @ Qty: 1+ | ||
 | Zoro | G3604151 | 513.63 | 513.63 | 1 | In Stock | 26 | Eaton | 2.65 | 513.63 @ Qty: 1+ |
 | kempstoncontrols.co.uk | CN15DN3TB | 552.86478 | 552.86478 | 1 | In Stock | Eaton | 552.86478 @ Qty: 1+ | ||
 | cappusa.com | 4840632 | 556.33 | 556.33 | 1 | In Stock | Eaton | 556.33 @ Qty: 1+ | ||
 | sustainablesupply.com | C2883492 | 646.04 | 646.04 | 1 | In Stock | Eaton | 2.65 | 646.04 @ Qty: 1+ | |
| Galco | CN15DN3TB | 779.17 | 779.17 | 1 | In Stock | Cutler Hammer, Div of Eaton Corp | 1.0 | 779.17 @ Qty: 1+ | ||
 | Platt.com | 0454700 | 794.93 | 794.93 | 1 | 2 | Eaton | 794.93 @ Qty: 1+ | ||
 | electricalparts.com | CN15DN3TB | 801.7632 | 801.7632 | 1 | 2 | Eaton | 801.7632 @ Qty: 1+ | ||
 | crescentelectric.com | 721331 | 904.58 | 904.58 | 1 | In Stock | Eaton | 904.58 @ Qty: 1+ | ||
| us.rs-online.com | 71562573 | 918.36 | 918.36 | 1 | In Stock | Eaton - Cutler Hammer | 918.36 @ Qty: 1+ | |||
 | motorsandcontrol.com | CN15DN3TB | 954.48 | 954.48 | 1 | In Stock | Eaton Cutler Hammer | 954.48 @ Qty: 1+ |
