- mpnFAZ-D16/3-NA
- brandname: Eaton / Cutler Hammer
- manufacturername: Eaton / Cutler Hammer
Eaton / Cutler Hammer FAZ-D16/3-NA Miniature Circuit Breaker 16 Amp 277/480 Volt AC 125 Volt DC 3-Pole DIN Rail Mount
- Brand: Eaton Cutler-Hammer
- PackageQuantity: 1
- Manufacturer: Eaton / Cutler Hammer
- Label: Eaton / Cutler Hammer
Attributes
| Key | Value |
|---|
| AC Voltage Rating | 277/480V AC |
| Actuator Type | Toggle |
| Amperage | 16 |
| Amperage Rating | 16 |
| Amps | 16 A, 16 |
| Application | Motor Control Circuits,. |
| Approval | UL, CSA, IEC, CE, VDE |
| Approvals | UL 489 ; CSA Std. C22.2. |
| Brand | Eaton |
| Catalog Number | FAZ-D16/3-NA |
| Characteristic | D Curve |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mountin. | DIN Rail |
| Connection | Screw Terminal |
| Connection Type | Feed-Thru |
| Country of Origin | Spain |
| Current Rating | 16 A |
| Curve Type | D |
| DC Voltage Rating | 48/96V DC |
| Depth | 4.25 in |
| Family / Style | FAZ-NA |
| Frame | 45 mm |
| Frame Size | 40A/FAZ |
| Frame Type | FAZ |
| Functions | LI - Long Time and Inst. |
| Height | 4.13 Inch |
| Interrupt Rating | 10 Kilo-Amp, 14 Kilo-Amp |
| Interrupt Rating AC | 10 kA |
| Interrupting Rating | 14kAIC, 10kAIC |
| Item | IEC Miniature Circuit B. |
| Item Type | Branch protector |
| Length | 2.1 in, 2.0 in |
| Length (Straight Wirewa. | 2.0 in |
| Made in USA | No |
| Manufacturer | Eaton Cutler Hammer, Ea. |
| Max Wire Size | 6 AWG |
| Max. AIR Rating | 14kA at 277/480V AC |
| Max. Wire Size | 6 AWG |
| Meets UL Type | UL 489 |
| Min Wire Size | 18 AWG |
| Min. Wire Size | 18 AWG |
| Mounting | DIN Rail |
| Mounting Type | DIN Rail Mount, DIN Rail |
| Mpn | FAZ-D16/3-NA |
| Number of Poles | 3 |
| Part Number | FAZ-D16/3-NA |
| Phase | 3 |
| Poles | 3 |
| Protection | Thermal Magnetic |
| Series | FAZ, FAZ-NA, FAZ-NA Ser. |
| Standard | CSA Std. C22.2 No. 235,. |
| Standards | CSA Certified, IEC 6094. |
| Temperature Rating | -4 to 140?F |
| Terminal Connection | Screw Clamp, Line and l. |
| Terminals | Standard terminals |
| Termination | Screw |
| Trip Range | 10 - 20 Times Current R. |
| Trip Type | Thermal Magnetic, 10-20. |
| Type | Trip Curve D, Thermal/M. |
| Upc | 4015081021468 |
| UPC Code | 4015081021468 |
| Voltage | 277/480VAC, 48/96VDC |
| Voltage Rating | 277/480 Volt AC, 125 Vo. |
| Volts AC | 277, 480Y |
| Volts DC | 48 |
| Width | 0 in, 3.0 in |
| Wire Gauge | 18 to 6 AWG, 18 to 10 A. |
| Wire Size | 18-6 AWG at One Wire, 1. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Platt.com | 0058611 | 60.08 | 1 | 43 | | Eaton | | 60.08 @ 1 |
 | cappusa.com | 4874905 | 88.08 | 1 | In Stock | | Eaton | | 88.08 @ 1 |
 | Walker Industrial | FAZ-D16-3-NA | 126.2 | 1 | In Stock | | Eaton Cutler-Hammer | | 126.2 @ 1 |
 | motorsandcontrol.com | FAZ-D16/3-NA | 133.45 | 1 | In Stock | | Eaton Cutler Hammer | | 133.45 @ 1 |
 | Carlton Bates Company | 01508102146 | 139.74 | 1 | In Stock | | EATON | | 139.74 @ 1 |
| Airline Hydraulics | EATON FAZ-D16/3-NA | 144.36 | 1 | In Stock | | Eaton | | 144.36 @ 1 |
 | Zoro | G7581271 | 168.99 | 1 | In Stock | 26 | Eaton | 0.8 | 168.99 @ 1 |
 | superbreakers.com | FAZ-D16/3-NA | 189.65 | 1 | 4 | | Eaton | | 189.65 @ 1 |
| us.rs-online.com | 70276082 | 199.68 | 1 | 122 | | Eaton - Cutler Hammer | | 199.68 @ 1 |
| Newark | 58M6315 | 218.17 | 1 | In Stock | | EATON MOELLER | | 218.17 @ 1 |
 | Raptor Supplies | AF6MJU | 222.1850475 | 1 | In Stock | | EATON | | 222.1850475 @ 1 |
 | crescentelectric.com | 103245 | 422.47 | 1 | In Stock | | Eaton | | 422.47 @ 1 |
