Attributes
| Key | Value |
|---|---|
| ANSI Number | CV50HC06M350 |
| Balanced to RPM | 25,000 RPM |
| Bore Dia. | 69.8500mm |
| Coolant Fed | Coolant Through |
| Country of Origin (subject to change) | Slovenia |
| Features | Maximum T.I.R. only 0.0001 in |
| Hole Dia. | 1/4 in |
| Item | Hydraulic Chuck |
| Nose Dia. | 53/64 in |
| Overall Length | 190.50mm |
| Projection | 160.00mm |
| Series | HSK100A ShrinkFit |
| Shank Dia. | 1/4 in |
| Shank Type - Machining | Taper |
| Standards | ANSI B5.50 |
| Taper | CV50 |
| Taper Size | HSK100A |
| Tool Depth | 1-27/64 in |
