Attributes
| Key | Value |
|---|---|
| Alternate Part No. | 512-MCT61SD |
| Base Product Number | MCT61 |
| Brand | Fairchild Semiconductor |
| Category | Isolators |
| Configuration | 2 Channel |
| Current - DC Forward (If) (Max) | 60 mA |
| Current - Output / Channel | 30mA |
| Current Transfer Ratio (Max) | - |
| Current Transfer Ratio (Min) | 50% @ 5mA |
| Input Type | DC |
| Isolation Voltage | 5000 Vrms |
| Manufacturer | Fairchild Semiconductor |
| Manufacturer Part No. | MCT61SD |
| Maximum Collector Current | 30 mA |
| Maximum Collector Emitter Saturation Voltage | 0.4 V |
| Maximum Collector Emitter Voltage | 30 V |
| Maximum Forward Diode Voltage | 1.5 V |
| Maximum Input Diode Current | 60 mA |
| Maximum Operating Temperature | + 100 C |
| Maximum Power Dissipation | 400 mW |
| Maximum Reverse Diode Voltage | 25 V |
| Mfr | onsemi |
| Minimum Operating Temperature | - 55 C |
| Mounting Type | Surface Mount |
| Number of Channels | 2 |
| Number of Channels per Chip | 2 Channels |
| Operating Temperature | -55?C ~ 100?C |
| Output Device | NPN Phototransistor |
| Output Type | Transistor, DC |
| Package | Tape & Reel (TR) |
| Package / Case | 8-SMD, Gull Wing |
| Package/Case | PDIP-8 Gull Wing |
| Packaging | Reel |
| Product Category | Transistor Output Optocouplers |
| Product Status | Active |
| Rise / Fall Time (Typ) | - |
| Series | -, MCT61 |
| Supplier Device Package | 8-SMD |
| Turn On / Turn Off Time (Typ) | 2.4?s, 2.4?s |
| Unit Weight | 774 mg |
| Vce Saturation (Max) | 400mV |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Voltage - Isolation | 5000Vrms |
| Voltage - Output (Max) | 30V |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Hotenda | H2746906 | 0.3327 | 2.12928 | 1 | 10 | Fairchild Semiconductor | 0.3327 @ Qty: 10+ | |||
| Newark | 79AH4001 | 0.355 | 428.13 | 3000 | 10 | ONSEMI | 0.355 @ Qty: 3000+ | |||
| Digi-Key | 3479528 | 0.729 | 4.6656 | 1 | 997 | onsemi | 0.729 @ Qty: 10+ | |||
 | swatee.com | MCT61SD | 1.75 | 11.2 | 1 | 176 | Fairchild Semiconductor | 1.75 @ Qty: 10+ |
