Attributes
| Key ^ | Value |
|---|---|
| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 2.38 in (60.45 Mm) |
| (c) Inner Diameter, Top | 1.38 in (35.05 Mm) |
| (e) Length | 8.00 in (0.00 Mm) |
| (f) Thread, Handle | None |
| Center Tube, Type of End Cap | Plated Steel |
| Configuration | Single Open End |
| Direction of Flow | Outside->in |
| Filter Area | Sq.in. |
| Maximum Temperature | 225 F |
| Micron Rating | 74.00 Absolute |
| Outer Jacket | None - None |
| Plating | Zinc Plated |
| Recommended Changeout Differential Pressure | 50 Psid |
| Seal Material | Buna-n |
| Type of Adhesive | Epoxy |
| Type of Media | 304 Stainless Steel Wire |
