Key ^ | Value |
---|---|
(a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 5.12 in (130.05 Mm) |
(c) Inner Diameter, Top | 0.75 in (19.05 Mm) |
(d) Inner Diameter, Bottom | 2.56 in (65.02 Mm) |
(e) Length | 8.00 in (65.02 Mm) |
(f) Thread, Beta Rating, Plating | N/a |
Center Tube | Steel |
Collapse Pressure Rating | 58 Psi |
Configuration | Double Open End |
Direction of Flow | Outside->in |
Filter Area | 458 Sq.in. |
Handle, Outer Jacket | None |
Maximum Temperature | 250 F |
Micron Rating | 125.00 |
Recommended Changeout Differential Pressure | 25 Psid |
Seal Material | Buna |
Type of Adhesive | Epoxy |
Type of End Cap | Plated Steel |
Type of Media | 304 Stainless Steel Wire |
