| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 1.85 in (46.99 Mm) |
| (c) Inner Diameter, Top | 0.87 in (22.10 Mm) |
| (e) Length | 6.02 in (0.00 Mm) |
| (f) Thread, Handle, Outer Jacket | None |
| Beta Rating | B50=200 |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 435 Psi |
| Configuration | Single Open End |
| Direction of Flow | Outside->in |
| Filter Area | 151 Sq.ft. |
| Maximum Temperature | 225 F |
| Micron Rating | 50.00 |
| Plating | N/a |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Buna-n |
| Type of Adhesive | Epoxy |
| Type of Media | Wire Mesh |
