| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 3.90 in (99.06 Mm) |
| (c) Inner Diameter, Top | 2.09 in (53.09 Mm) |
| (d) Inner Diameter, Bottom | 2.07 in (52.58 Mm) |
| (e) Length | 8.58 in (52.58 Mm) |
| (f) Thread, Filter Area, Plating | N/a |
| Beta Rating | B25=200 |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 150 Psid |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Handle, Outer Jacket | None |
| Maximum Temperature | 225 F |
| Micron Rating | 25.00 Nominal |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Buna-n |
| Type of Adhesive | Epoxy |
| Type of Media | Stainless Steel Wire Mesh |
