Attributes
| Key ^ | Value |
|---|---|
| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 1.78 in (45.21 Mm) |
| (c) Inner Diameter, Top | 0.76 in (19.30 Mm) |
| (e) Length | 3.18 in (0.00 Mm) |
| (f) Thread, Filter Area, Plating | N/a |
| Beta Rating | B25=200 |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 450 Psid |
| Configuration | Single Open End |
| Direction of Flow | Outside->in |
| Handle, Outer Jacket | None |
| Maximum Temperature | 225 F |
| Micron Rating | 25.00 |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Buna |
| Type of Adhesive | Epoxy |
| Type of Media | Wire Mesh |
