| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 3.90 in (99.06 Mm) |
| (c) Inner Diameter, Top, (d) Inner Diameter, Bottom | 2.04 in (51.82 Mm) |
| (e) Length | 8.27 in (51.82 Mm) |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 250 Psid |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Handle, Outer Jacket, Seal Material | None |
| Maximum Temperature | 225 F |
| Micron Rating | 500.00 |
| Plating | Zinc Plated |
| Recommended Changeout Differential Pressure | 0 Psid |
| Type of Adhesive | Epoxy |
| Type of Media | 304 Stainless Steel Wire |
