| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 2.80 in (71.12 Mm) |
| (c) Inner Diameter, Top, (d) Inner Diameter, Bottom | 1.06 in (26.92 Mm) |
| (e) Length | 5.00 in (26.92 Mm) |
| (f) Thread, Filter Area, Plating | N/a |
| Beta Rating | B74=200 |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 75 Psid |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Handle, Outer Jacket | None |
| Maximum Temperature | 250 F |
| Micron Rating | 74.00 Absolute |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Epr |
| Type of Adhesive | Epoxy |
| Type of Media | Wire Mesh |
