Attributes
| Key ^ | Value |
|---|---|
| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 5.62 in (142.75 Mm) |
| (c) Inner Diameter, Top | 3.78 in (96.01 Mm) |
| (d) Inner Diameter, Bottom | 0.42 in (10.67 Mm) |
| (e) Length | 14.16 in (10.67 Mm) |
| Center Tube, Type of End Cap | Plated Steel |
| Collapse Pressure Rating | 150 Psid |
| Configuration | Single Open End W/bh |
| Direction of Flow | Outside->in |
| Filter Area | Sq.in" |
| Handle, Outer Jacket | None |
| Micron Rating | 100.00 Absolute |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Buna-n |
| Type of Adhesive | Epoxy |
| Type of Media | Wire Mesh |
