Attributes
| Key ^ | Value |
|---|---|
| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 5.09 in (129.29 Mm) |
| (c) Inner Diameter, Top, (d) Inner Diameter, Bottom | 2.77 in (70.36 Mm) |
| (e) Length | 15.74 in (70.36 Mm) |
| (f) Thread, Handle, Outer Jacket | None |
| Beta Rating | N/a |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Filter Area | Sq. In." |
| Micron Rating | 74.00 Absolute |
| Plating, Type of End Cap | Plated Steel |
| Recommended Changeout Differential Pressure | 0 Psid |
| Seal Material | Viton |
| Type of Adhesive | Epoxy |
| Type of Media | Wire |
