| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 5.35 in (135.89 Mm) |
| (c) Inner Diameter, Top, (d) Inner Diameter, Bottom | 3.56 in (90.42 Mm) |
| (e) Length | 7.88 in (90.42 Mm) |
| (f) Thread, Beta Rating, Collapse Pressure Rating, Filter Area, Seal Material | N/a |
| Center Tube, Type of End Cap | Plated Steel |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Handle, Outer Jacket | None |
| Maximum Temperature | 250 F |
| Micron Rating | 250.00 |
| Plating | Nickel Plated |
| Recommended Changeout Differential Pressure | 25 Psid |
| Type of Adhesive | Epoxy |
| Type of Media | 304 Stainless Steel Wire |
