B00GS3VF7K

Fluke FLUKE-700RG29 Pressure Gauge, Reference, 3000 PSIG

Attributes

Key Value
Accuracy Grade Gauge Ty.Process
Adjustable Set PointsNo
Agency ComplianceCSA: Class 1, Div2, Gro.
Ambient Operating Tempe.-10 Degrees to 55 Degr.
ApprovalsATEX, CE, CSA, EMC
Auto-ShutoffYes
Auto-Shutoff Time1 min, 30 min
AvailabilityIn Stock, ships within .
Backlit ScreenYes
Bar Graph20 Segments
Basic Gauge Case Materi.Metal
Basic Gauge Wetted PartsStainless Steel
Battery life1,500 hours without bac.
Battery Run Time1,500 hr
Battery Type(3) AA Alkaline Batteri.
Blowout Safety BackNo
BrandFluke
Burst Pressure10,000 psi, 10000 psi, .
Calibration CertificateNIST Traceable
Case ColorYellow
Case ConstructionRugged
Case Diameter3.75 in
Case MaterialCast Znal
Case ShapeRound
CategoryTest and Measurement
CommentsAny liquids or gases co.
Compatible Brand and Se.Fluke 700 Series
Compatible Grainger Par.16L018, 16L019
Compatible Manufacturer.700HTPK, 700PTPK
Compatible Process MediaAny Clean Dry Non-Corro.
ConditionNew
Connection1/4 NPT
Connection LocationBottom
Country of Origin (subj.China
Current Stock5
DescriptionPRESSURE GAUGE REFERENCE
Detailed DescriptionManometer For Measuring.
Differentiator (HIDDEN)FLUKE-700RG29 Yes
Digi-Key Part NumberFLUKE-700RG29-ND
Digit Height0.65 in
Digital Gauge Accuracy+/-0.04% of Reading
Digital Gauge Display U.bar, psi
Digital Pressure and Va.Digital Compound Gauge
Dimensions (H x W x D)12.7 x 11.4 x 3.7 cm (5.
DisplayMultiline LCD, 5-1/2 di.
Display Range-14 to 3,000 psi
Display Resolution0.01 bar
Display Screen Height0.65 in
Display Screen TypeLCD
Family SeriesFluke Panel Meters & Ga.
For MeasuringPressure (Liquid)
Gauge Connection Locati.Bottom
Gauge Connection Size1/4 in
Gauge Connection TypeMNPT
Gauge Mounting TypeStem-Mount
Gauge Nominal Dial Size3 3/4 in
Gauge Operating Temp. R.-14 Degrees to 131 Deg.
Gauge Primary Range Uni.psi
Gauge Primary Range Val.-14 to 0 to 3000
Gauge Wetted PartsStainless Steel
Gross Weight2 lbs
GTIN#095969674201
Hazardous Location Rati.Not Rated
Housing/WeightCast ZNAL 0.56 kg (1.22.
IncludesCalibration Certificate.
Includes BatteriesNo
Includes Calibration Ce.Yes
Includes Mounting Hardw.No
Includes Rubber BootNo
International ShippingNo
IP/NEMA RatingIP67
ItemDigital Test Compound G.
Item NumberFLUKE-700RG29
LanguagesEnglish
Low Battery IndicatorYes
ManufacturerFluke, Fluke Electronics
Manufacturer Part Number4353622
Manufacturer Product Nu.FLUKE-700RG29
Manufacturer Standard L.2 Weeks
Manufacturer Warranty L.3 yr
Manufacturers Warranty .3 yr
MaterialHAWA
Maximum Value3,000
Memory Storage Capacity8493 Readings
MfrFluke Electronics
Minimum Value-14
MpnFLUKE-700RG29
MPNFLUKE-700RG29
Net Weight0 lbs
Nominal Dial Size3 3/4 in
Non-SparkingNo
Number of Digits5
PackageBulk
Panel-MountableNo
Peak HoldNo
PowerThree (3) AA alkaline b.
Power SourceBattery
Powered By(3) AA Batteries
Pressure connection1/4 in NPT Male
Pressure Gauge TypeTest Pressure Gauge
Pressure Range?14 to 3000 psi,
Pressure Range TypeCompound
Primary Display Range-14 to 3,000
Primary Display Unitspsi
Primary Range-14 to 3,000
Primary Unitspsi
Process Connection Gend.Male
Process Connection Loca.Bottom
Process Connection Size1/4 in
Process Connection TypeNPT
Process Temperature Ran.-14 Degrees to 131 Deg.
Product Series700G
Product StatusActive
Promotion RestrictionNot eligible for promot.
Range-14-3,000 psi, -14 to 3.
Resolution0.1 ; 0.01 psi ; bar
SeriesFluke-700G, 700G Series.
SKUCU-3139594D3137
Socket MaterialStainless Steel
StandardsCalifornia Proposition .
SubCategoryTest Instruments
Test Pressure Gauge TypeCalibrator Pressure Gau.
TypePressure, Manometer
UnitsDual Scale: psi, bar
UPC095969674201
UPC Code095969674201
Vacuum MeasurementYes
WeatherproofNo
With Calibration Certif.With Calibration Certif.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialstores.com700RG291070.451In StockFluke1070.45 @ 1
thumbzoomwilliamsautomation.com700RG291200.0120FLUKE1200.0 @ 1
thumbzoomLighting SupplyFLUKE-700RG291209.991In StockFluke1209.99 @ 1
thumbzoomWalker IndustrialFLUKE-700RG291244.991In Stock10Fluke1244.99 @ 1
RS Delivers798-87641386.58815Fluke1386.588 @ 1
thumbzoomCole-Parmer68088221393.991In Stock19Fluke1393.99 @ 1
thumbzoomZoroG61604541458.0118Fluke2.21458.0 @ 1
thumbzoomvaluetronics.comFLUKE_700RG29_NEW1477.991In StockFluke1477.99 @ 1
thumbzoomRadwell700RG291500.01In StockFLUKE1500.0 @ 1
thumbzoomsimsupply.comCU-3139594D31371532.41In StockFluke1532.4 @ 1
us.rs-online.com703164481537.991In StockFluke1537.99 @ 1
globaltestsupply.com700RG291537.991In StockFluke Corporation1537.99 @ 1
kirbyrisk.com31592991537.991In StockFluke1537.99 @ 1
thumbzoomjensentools.com37590.11537.991In StockFluke1537.99 @ 1
Platt.com20174721537.991In StockFluke1537.99 @ 1
thumbzoomprimebuy.comFLUKE-700RG291537.991In StockFluke0.561537.99 @ 1
thumbzoomDigi-Key50131451538.01In StockFluke Electronics1538.0 @ 1
thumbzoomsustainablesupply.comC17583501571.371In StockFluke2.21571.37 @ 1
thumbzoomturtle.comFLK FLUKE-700RG291599.391In StockFluke1599.39 @ 1
thumbzoomNewark08X54211614.991In StockFLUKE1614.99 @ 1
thumbzoomGalcoFLUKE-700RG29-FLKE1727.281In StockFluke2.01727.28 @ 1
