Attributes
| Key ^ | Value |
|---|---|
| Body Orientation | Right Angle |
| Brand | Glenair |
| Contact Plating | Gold |
| Current Rating | 3A |
| Depth | Depth |
| Dimensions | 30.42 x 9.25 x 6.13mm |
| Gender | Female |
| Housing Material | Liquid Crystal Polymer |
| Length | 30.42mm |
| Maximum Operating Temperature | +150?C |
| Minimum Operating Temperature | -55?C |
| Mounting Type | Through Hole |
| Number Of Contacts | 15 |
| Pitch | 2.54mm |
| Series | GMSM |
| Width | 9.25mm |
