Goulds 9BF1L9A0
Gouldszoom

Goulds 9BF1L9A0

mpn:
9BF1L9A0
brand:
Goulds Water Technology
manufacturer:
Goulds Water Technology
MPN:
9BF1L9A0
Weight:
12.5625
Weight:
201.0 LB
Preferred Price:
7220.87
Price:
7220.87
Min Simple Price:
4079.59
Absolute Min Price:
5793.01
Min Price:
5793.01
Dimensions:
[25.0, 17.0, 16.0]
qty:
21
simpleSku:
MxMDQ4:::9BF1L9A0
sku:
MxMDQ4::H4:9BF1L9A0@y0
condition:
11
seller:
sustainablesupply.com
amzMan:
goulds water technology
HazMat:
False
DropShip:
True

Attributes

Key ^Value
Agency ComplianceNSF 61
Amps23.6/11.8
Best Efficiency Flow90 gpm
Best Efficiency GPM @ Head90 gpm @ 235 ft
Best Efficiency Head235 ft
BrandGOULDS WATER TECHNOLOGY
Compatible Discharge Pipe Size1 in
Compatible Intake Pipe Size2 in
Compatible with Media TypeWater
ConnectionFlange
Connection Type, Discharge Type, Intake TypeNPT
Country of OriginUSA
Country of Origin (subject to change)United States
Discharge1"
Discharge Rotation90 Degrees Increments
ElastomersBUNA-N
FeaturesBack Pull Out to Reduce Maintenance Down Time, Dynamic Balancing, Renewable Wear Rings
Flow Rate (Maximum), Maximum Flow Rate110 gpm
Flow Rate (Minimum), Minimum Flow Rate30 gpm
Flow Rate @ 1 ft of Head (Maximum), Flow Rate @ 10 ft of Head (Maximum), Flow Rate @ 100 ft of Head (Maximum), Flow Rate @ 120 ft of Head (Maximum), Flow Rate @ 140 ft of Head (Maximum), Flow Rate @ 15 ft of Head (Maximum), Flow Rate @ 160 ft of Head (Maximum), Flow Rate @ 180 ft of Head (Maximum), Flow Rate @ 20 ft of Head (Maximum), Flow Rate @ 200 ft of Head (Maximum), Flow Rate @ 30 ft of Head (Maximum), Flow Rate @ 300 ft of Head (Maximum), Flow Rate @ 40 ft of Head (Maximum), Flow Rate @ 5 ft of Head (Maximum), Flow Rate @ 50 ft of Head (Maximum), Flow Rate @ 60 ft of Head (Maximum), Flow Rate @ 70 ft of Head (Maximum), Flow Rate @ 80 ft of Head (Maximum), Flow Rate @ 90 ft of Head (Maximum)Not Applicable
Flow Rate @ 220 ft of Head (Maximum), Maximum Flow Rate @ 220 Feet of Head104 gpm
Flow Rate @ 240 ft of Head (Maximum), Maximum Flow Rate @ 240 Feet of Head86 gpm
Flow Rate @ 260 ft of Head (Maximum), Maximum Flow Rate @ 260 Feet of Head68 gpm
Flow Rate @ 280 ft of Head (Maximum), Maximum Flow Rate @ 280 Feet of Head34 gpm
For Use With Potable SystemsYes
Frequency60 Hz
Horsepower, HP - Pumps10 hp
HousingBronze Fitted
Housing Material, Housing Material - Pumps, Impeller Material, Wetted MaterialsBronze
HP10
Hz60
Impeller DesignClosed
Impeller Size8.06"
Impeller TypeEnclosed
Inlet2" NPT, 2"
Inlet Size - Pumps2 in NPT
Intake and Discharge Size2 in , 1 in
ItemCentrifugal Pump
Item - Straight Centrifugal PumpsStraight Centrifugal High Flow Pump
Item?49UU67
Manufacturer Part Number, Mfr. Model?, MPN9BF1L9A0
Manufacturer Warranty Length, Manufacturers Warranty Length1 yr
Max Flow109.00 GPM
Max Head285.00 FT
Max Temp (?F)212
Max. Case Pressure200 psi
Max. GPM @ Head110 @ 210 ft
Max. Head270 ft
Max. Liquid Temp., Maximum Media Temperature212 Degrees F
Maximum Feet of Head285 ft
Maximum RPM, RPM (Maximum)3,500 RPM
Mechanical SealCarbon vs. Ceramic
Min. GPM @ Head30 @ 280 ft
MotorTEFC-PE
Motor EnclosureTotally Enclosed Fan Cooled (TEFC), Totally Enclosed Fan Cooled
Motor Enclosure Broad, Motor Enclosure TypeTEFC
Motor RPM, Speed (RPM)3500
Motor TypeJM
Mounting OrientationHorizontal
Nameplate Voltage, Nominal Voltage230/460V AC
Old Part Number9BF1L5A0
Outlet1" NPT
Outlet Size - Pumps1 in NPT
Overall Length24.7 in
PhaseThree
Phase, Phase - Pumps, Phase Broad3
PrimingManual
Product TypeSimple product
Pump Housing MaterialCast Iron
Pump Housing Material BroadCI
Pumping ApplicationBooster Service, Irrigation, Liquid Transfer, Spraying Systems, Water Circulation
Seal Material316 Stainless Steel, Buna Elastomer, Carbon, Ceramic, 316 Stainless Steel; Buna Elastomer; Carbon; Ceramic
Seal TypeMechanical Type 21
Series3656, 3656 S-Group
Shaft MaterialStainless Steel
Shut Off Pressure, Shut Off Pressure (Maximum)175 psi
StandardsANSI 61; NSF Certified, ANSI 61, NSF Certified
UNSPSC40151503
UPC69766651067
Voltage230/460VAC, 230/460V
Voltage - Pumps240/460V AC
Weight165.000000
Wetted Material316 Stainless Steel; Bronze; Buna-N; Carbon; Ceramic, 316 Stainless Steel, Bronze, Buna-N, Carbon, Ceramic

All Prices

ImgSellerSupplier SKURequested Price ^Calc MOQ PriceMOQIn StockLead TimeBrandWeightPreferred Tier
thumbzoomsustainablesupply.comC29840404079.594079.591In StockGoulds Water Technology201.04079.59 @ Qty: 1+
Grainger49UU674332.224332.221In StockGOULDS WATER TECHNOLOGY4332.22 @ Qty: 1+
AmazonTPB07HJT2VZ84358.414358.411In Stock2GOULDS WATER TECHNOLOGY4358.41 @ Qty: 1+
thumbzoomandersonprocess.com9BF1L9A04497.54497.51In Stock35Goulds Water Technology165.04497.5 @ Qty: 1+
thumbzoompumpproducts.com9BF1L9A04497.54497.51In Stock10Goulds4497.5 @ Qty: 1+
thumbzoomZoroG48477204697.54697.51In Stock50Goulds Water Technology201.04697.5 @ Qty: 1+
B08GZYS5H4
Goulds 9BF1L9A0

GOULDS Water Technology 9BF1L9A0 Pump,10 HP,3 Ph,240/460VAC

GOULDS Water Technology 9BF1L9A0 Pump,10 HP,3 Ph,240/460VACzoom
