Grayhill 44D30-01-2-AJS

B00DK88LJ6

Rotary Switches Rotary Switch, Standard, adjustable stops, 30-deg;, 1 deck, 2 pole/deck, shorting

Rotary Switches Rotary Switch, Standard, adjustable stops, 30-deg;, 1 deck, 2 pole/deck, shortingzoom

Attributes

Key Value
AC Voltage115 V
Actuator Length11.10mm
Actuator TypeFlatted Shaft ; 6.35 mm.
Angle of Throw30?
Base Product Number44D30
CategorySwitches
Circuit per DeckDP6T
Contact Finish-
Contact FormDP6T
Contact MaterialSilver Alloy
Contact TimingShorting (MBB)
Current Rating1 A
Current Rating (Amps)1A (AC/DC)
DC Voltage28 V
Depth1.025 in
Depth Behind Panel26.04mm
DescriptionSWITCH ROTARY 2-6POS 1A.
Detailed DescriptionRotary Switch 2 ~ 6 Pos.
Digi-Key Part Number44D30-01-2-AJS-ND
Features-
FunctionShorting (MBB)
Index StopsAdjustable
IndexingAdjustable
ManufacturerGrayhill Inc.
Manufacturer Product Nu.44D30-01-2-AJS
Manufacturer Standard L.15 Weeks
MfrGrayhill Inc.
Mounting Hole Size0.375 in
Mounting TypePanel Mount
Number of Decks1
Number of Poles2
Number of Poles per Deck2
Number of Positions2 to 6, 2 ~ 6
PackageBulk
Panel Cutout Dimensions-
Product StatusActive
Series44, 44 Series
TerminationSolder Lugs
Termination StyleSolder Lug
Voltage Rating - AC115 V
Voltage Rating - DC28 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Future ElectronicsC00835214533.38410In StockGrayhill33.384 @ 10
thumbzoomDigi-Key77006147.0510In StockGrayhill Inc.47.05 @ 10
us.rs-online.com7021698352.4810In StockGrayhill52.48 @ 10
Newark03B506680.2110In StockGRAYHILL80.21 @ 1
thumbzoomRadwell44D30-01-2-AJS100.010In StockGRAYHILL INC100.0 @ 10
