mpn:
brand:
manufacturer:
MPN:
Description:
Crimp D Connector (Male Tinned Metal Shell w Dimples) 37 position
Weight:
0.07625
Weight:
0.07625 LB
Preferred Price:
3.58
Price:
3.58
Min Simple Price:
1.24
Absolute Min Price:
2.91
Min Price:
2.91
Dimensions:
[23.0, 16.0, 11.0]
qty:
41
simpleSku:
OTI0MQ:::09670375601
sku:
OTI0MQ::SQ:09670375601@y0
condition:
11
seller:
Newark
amzMan:
harting
HazMat:
False
DropShip:
False
Attributes
| Key | Value |
|---|---|
| Application | Standard |
| Cable Clamping Method | Crimp |
| Category | Connectors, Interconnects |
| Color | - |
| Connection Type | Crimp |
| Connector Gender | Male |
| Connector Style | D-Sub |
| Connector Type | Plug for Male Contacts |
| Contact Material | Copper Alloy |
| Contact Type | Signal |
| D-Sub Shell Size | D-Sub 4 |
| Description | CONN D-SUB HOUSING PLUG 37POS |
| Detailed Description | Plug for Male Contacts Housing D-Sub Connector 37 Position |
| Dielectric Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Digi-Key Part Number | 1195-2736-ND |
| Features | Grounding Indents |
| Flange Feature | Housing/Shell (Unthreaded) |
| Housing Material | Plated Steel |
| Ingress Protection | - |
| Insert Color | Black |
| Insert Material | Thermoplastic Resin Glass-Fibre Filled (PBTP) |
| Item | Fixing Flange D-Sub Connector |
| Locking Type | Fixing Flange |
| Manufacturer | HARTING |
| Manufacturer Product Number | 09670375601 |
| Manufacturer Standard Lead Time | 8 Weeks |
| Mating Cycles | - |
| Maximum Operating Temperature | 125 Degrees C |
| Mfr | HARTING |
| Minimum Insulation Resistance | 1.00 x 10^10 ohm |
| Minimum Operating Temperature | -55 Degrees C |
| Mounting Type | Panel Mount |
| Note | Contacts Not Included |
| Number of Poles | 37 |
| Number of Positions | 37 |
| Number of Rows | 2 |
| Operating Temperature | -55?C ~ 125?C |
| Operating Temperature Range | -55 Degrees C to 125 Degrees C |
| Package | Tray |
| Package Quantity | 1 |
| Product Status | Active |
| Series | D-Sub, - |
| Service Connector Type | Standard Density D-Sub Connector |
| Shell Finish Thickness | - |
| Shell Material, Finish | Steel, Tin Plated |
| Shell Size, Connector Layout | 4 (DC, C) |
| Standards | IEC 60807-3, UL 1977 ECBT2.E102079 |
| Type | Male |
| Wire Size | 28 to 18 AWG |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Newark | 96F2630 | 1.24 | 1.24 | 1 | 49 | HARTING | 1.24 @ Qty: 1+ | ||
 | TME | 09670375601 | 2.4 | 2.4 | 1 | 41 | HARTING | 2.4 @ Qty: 1+ | ||
| Hotenda | H1191448 | 2.43 | 2.43 | 1 | 27 | HARTING | 2.43 @ Qty: 1+ | |||
| RS Delivers | 100-7765 | 3.024 | 3.024 | 1 | 118 | HARTING | 3.024 @ Qty: 1+ | |||
 | Digi-Key | 3181320 | 3.156 | 3.156 | 1 | 41 | HARTING | 3.156 @ Qty: 1+ | ||
 | Zoro | G305285925 | 8.6 | 18.92 | 4 | 41 | Harting | 1.22 | 8.6 @ Qty: 4+ |
