Attributes
| Key ^ | Value |
|---|---|
| Angle | Straight |
| Application | Straight Male- Form 2 |
| Approvals | CSA, UL |
| Brand | Hubbell Wiring Device - Kellems |
| Cable Diameter (in) | 0.25-0.38 " |
| Cable Diameter (mm) | 6.35-9.53 mm |
| Cable Diameter Range | 0.250 in-0.375 in |
| Cable size | 0.250 in-0.375 in (0.63-0.95) |
| Cable Style | Round |
| Catalog Number, Item Number, Manufacturer Part Number | CG406SST |
| Certifications | UL Listed CSA Certified |
| Color, Composition | Metallic |
| Conductor range | 0.25-0.375 in (.63-.95 mm) |
| Deluxe Grip Form Size | F2 |
| Dimension A A/C | 1.30" (3.30) |
| Dimension A A/F | 1.13" (2.87) |
| Dimension B | 1.10" (2.79) |
| Dimension C | .54" (1.37) |
| Dimension D | .63" (1.60) Throat Dia. |
| Dimension E A/C | 1.16" (2.95) |
| Dimension E A/F | 1.00" (2.54) |
| Dimension F | 1/2" - 14 |
| Display size, Thread | 1/2 in NPT |
| Environmental conditions | Suitable For Use In Wet Locations When Used With A Listed Sealing Ring Between Box And Fitting. |
| Family Series | Hubbell Cable Entries |
| Fitting Flammability Rating | UL 94-V2 |
| Grip Cord Range (Diameter) | .250"- .375" (.63- .95) |
| Grip Style and Material | Straight Stainless Connector Stainless Grip |
| Grip Thread Size | 1/2" |
| Grip Type | Bushing Grip with Strain Relief |
| Gross Weight | 0.45 lbs |
| GTIN | 00783585334592 |
| Hazardous Locations | Suitable for use in hazardous locations per Class I, Div. 2, Class II, Div. 1 & 2, Class III, Div. 1 & 2. |
| Hazardous Rated, RoHS, Split Frame | No |
| Hub Size | 1/2 NPT |
| Industry Standard(s) | UL Listed |
| Item type, Product Type, Series | Deluxe Cord Grips |
| Manufacturer | Hubbell |
| Manufacturer, OEM brand name | Hubbell wiring device-kellems |
| Material | Stainless Steel Fittings, Stainless Steel Mesh, Stainless Steel |
| Material - mounting hardware, Mounting | Locknut or Tapped Opening |
| Maximum Cable Diameter (in) | 0.375 " |
| Maximum Cable Diameter (mm) | 9.53 mm |
| Mesh Grip Flammability Rating | UL 94-HB |
| Minimum Cable Diameter (in) | 0.25 " |
| Minimum Cable Diameter (mm) | 6.35 mm |
| Net Weight | 0 lbs |
| Number of Cables, Package Quantity | 1 |
| Number of conductors | Single |
| Operating Temperature | -30?F to +225?F (-34?C to +107?C) |
| Recommended Knockout Hole Size | .859 to .906 (2.18 - 2.30) |
| Style | For Insulated Cables |
| Temperature rating | Minimum -30 Deg F to 240 Deg F (-34 Deg C to 115 Deg C) |
| Thread Type | N.P.T. |
| UPC | 783585334592 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | CG406SST | 139.07 | 139.07 | 1 | 2 | HUBBELL | 139.07 @ Qty: 1+ | |||
 | Zoro | G000490167 | 213.99 | 213.99 | 1 | In Stock | Hubbell Wiring Device-Kellems | 213.99 @ Qty: 1+ | ||
| standardelectricsupply.com | 2320529 | 228.57 | 228.57 | 1 | In Stock | Hubbell | 228.57 @ Qty: 1+ | |||
 | MRO Supply | 1015904 | 228.57 | 228.57 | 1 | In Stock | Hubbell Wiring | 228.57 @ Qty: 1+ | ||
 | gordonelectricsupply.com | CG406SST | 229.1 | 229.1 | 1 | In Stock | HUBBELL | 229.1 @ Qty: 1+ | ||
 | Galco | CG406SST-HBBL | 235.29 | 235.29 | 1 | In Stock | Hubbell | 0.45 | 235.29 @ Qty: 1+ | |
 | crescentelectric.com | 379280 | 286.23 | 286.23 | 1 | In Stock | Hubbell Wiring Device - Kellems | 286.23 @ Qty: 1+ | ||
| kirbyrisk.com | 2072111 | 429.88 | 429.88 | 1 | In Stock | Hubbell | 429.88 @ Qty: 1+ |
