| Additional Electrical Protection, Additional Electrical Protections | Standard Protection |
| AFCI, Corrosion Resistant, GFCI, Power Indicator, Shrouded, Surge Protection, Surge Suppression, Tamper Resistant, Weather Resistant, Weather Resistant - Plugs and Receptacles | No |
| Amps - Plugs and Receptacles, Current Rating, Primary Resistance Properties | 15 A |
| Amps, Amps - Plugs and Receptacles | 15 |
| Application Environment, Market | Commercial |
| Color, Color - Plugs and Receptacles, Housing Color | White |
| Connection Orientation | Straight |
| Contact Material | Brass |
| Country of Origin (subject to change) | China |
| Cover Type | No Cover |
| Description | Smooth |
| Face Plate Height | 2.73 in |
| Face Plate Width | 1.32 in |
| Flange Type | Non-Flanged |
| For Location | Indoor |
| Grade | Federal Specification |
| Grounding | Grounded |
| Horsepower Rating, HP | 1/2 hp |
| Housing Material, Material | Nylon |
| Includes | Grounding Staple, Mounting Hardware, Wall Plate or Weatherproof Cover |
| Includes Mounting Hardware, Polarized | Yes |
| Item, Item - Plugs and Receptacles, Product Type | Receptacle |
| Key Resistance Properties | Standard Resistance |
| Maximum Operating Temperature | 75 Degrees C |
| Maximum Wire Size | 10 AWG |
| Minimum Operating Temperature | -40 Degrees C |
| Minimum Wire Size | 14 AWG |
| Mount Hole Center-to-Center Height, Overall Depth | 3.28 in |
| Mount Type, Mounting Type, Mounting Type - Plugs and Receptacles | Flush |
| NEMA Configuration | 5-15 |
| NEMA Enclosure Rating, Number of Gangs | 1 |
| NEMA Receptacle Configuration, NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Number of Poles | 2 |
| Number of Poles & Wires | 2 Pole / 3 Wire |
| Number of Wires | 3 |
| Outlet Type - Plugs and Receptacles | Standard Duplex |
| Outlet Type, Receptacle Type, Type | Duplex |
| Phase | Single |
| Standards | CSA Certified C22.2, Federal Specification W-C-596, NEMA WD-6, UL 498 |
| Sub-Category | Duplex Receptacles |
| UL 94 Flammability Rating | V-2 |
| Voltage | 125VAC |
| Voltage - Plugs and Receptacles, Voltage Rating | 125V AC |
| Wire Connection Type, Wire Connection Types | Screw Terminals |
| Wiring Method, Wiring Method - Plugs and Receptacles | Side |
