mpn:
brand:
manufacturer:
MPN:
Weight:
0.025
Weight:
0.04 LB
Preferred Price:
56.47
Price:
56.47
Min Simple Price:
30.86
Absolute Min Price:
43.82
Min Price:
43.82
Dimensions:
[4.0, 3.0, 3.0]
qty:
21
simpleSku:
DY4OTU:::HBL2411BK
sku:
DY4OTU::VM:HBL2411BK@y0
condition:
11
seller:
Onlinecomponents.com
amzMan:
hubbell
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Amperage, Amperage Rating | 20A |
| Amps, Amps - Plugs and Receptacles, IP Rating | 20 |
| Antimicrobial, Corrosion Resistant, International Shipping, Isolated Ground, Shrouded, Watertight | No |
| Application | Extra Heavy Duty Industrial |
| Approvals | CSA, UL |
| AWG Range | #16 AWG to #8 AWG |
| Blade Material | Brass |
| Body Length, Overall Length | 2.75 in |
| Body Type, Connection Orientation | Straight |
| Boot Code | C |
| Brand | Twist-Lock |
| Brand, Manufacturer | Hubbell |
| Color, Color - Plugs and Receptacles, Color Family, Housing Color, Housing Colour | Black |
| Cord dia | 35 in-1.15 in |
| Cord Size | 0.350 in to 1.150 in |
| Country of Origin | US - United States |
| Country of Origin (subject to change) | United States |
| Current Rating | 20 A |
| Current Stock | 47 |
| Display Type | Standard Sized |
| ECCN | EAR99 |
| Face Diameter | 2.21 in |
| Family Name | Twist-Lock? Family |
| Family Series | Hubbell Plugs & Receptacles |
| For Environment | Dry |
| For Location | Indoor |
| For Maximum Cable Diameter | 1.15 in |
| For Minimum Cable Diameter | 0.35 in |
| Grade, Grade - Plugs and Receptacles, Market | Industrial |
| Gross Weight | 0.3 lbs |
| Grounding | Grounded |
| Height, Width | 2.33 in. |
| Horsepower Rating | 2 hp |
| Housing Material, Material | Nylon |
| HP | 2, 1 Line to Neutral, 2 Line to Line |
| IP Rating | IP20 |
| Item Number, Manufacturer Part Number, Mpn | HBL2411BK |
| Item, Item - Plugs and Receptacles, Type | Locking Plug |
| Lead Time | Expected to ship in 1-2 business days |
| Length | 2.75 in. |
| Maximum Operating Temperature | 75 Degrees C, 75 Degrees C |
| Maximum Wire Size | 8 AWG |
| Minimum Operating Temperature | -40 Degrees C, -40 Degrees C |
| Minimum Wire Size | 16 AWG |
| NEMA Configuration, NEMA Plug Configuration, NEMA Plug Configuration - Plugs and Receptacles | L14-20P |
| NEMA Type | L14-20 |
| Net Weight | 0 lbs |
| No. of Poles, Number of Poles | 3 |
| No. of Wires, Number of Blades, Number of Wires | 4 |
| Outside Diameter | 2.33 in |
| Phase | 1, Single |
| Polarized | Yes |
| Rated Voltage, Voltage, Voltage - Plugs and Receptacles, Voltage Rating | 125/250V AC |
| Resistance Properties | Chemical Resistant, Impact Resistant |
| Series | Insulgrip Series |
| Shrouded / Non-Shrouded | Non-Shrouded |
| SKU | ZO-G1579663 |
| Special Features | Locking |
| Standard | Certified to CSA C22.2 No.42;Fed.Spec. W-C-596;Listed to UL 498 |
| Standards | UL, CSA, UL/CSA |
| SubCategory | Electrical |
| Termination | Screw |
| UL 94 Flammability Rating | HB |
| UNSPSC | 39121402 |
| UPC, UPC Code | 783585172309 |
| Voltage | 125/250VAC |
| Voltage Rating | 125 ; 250 V |
| Wire Connection Type | Screw Terminals |
| Wiring Style | Standard |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | HBL2411BK | 30.86 | 30.86 | 1 | In Stock | Hubbell | 30.86 @ Qty: 1+ | |||
 | MRO Supply | 1020719 | 39.71 | 39.71 | 1 | In Stock | Hubbell Wiring | 39.71 @ Qty: 1+ | ||
 | gordonelectricsupply.com | HBL2411BK | 40.31 | 40.31 | 1 | In Stock | HUBBELL | 40.31 @ Qty: 1+ | ||
 | Galco | HBL2411BK-HBBL | 40.88 | 40.88 | 1 | In Stock | Hubbell | 0.3 | 40.88 @ Qty: 1+ | |
 | Zoro | G1579663 | 41.83 | 41.83 | 1 | In Stock | Hubbell | 0.4 | 41.83 @ Qty: 1+ | |
 | simsupply.com | ZO-G1579663 | 43.24 | 43.24 | 1 | 47 | Hubbell | 43.24 @ Qty: 1+ | ||
| Grainger | 1DJK6 | 47.3 | 47.3 | 1 | 37 | 0 | HUBBELL WIRING DEVICE-KELLEMS | 47.3 @ Qty: 1+ | ||
| grainger.ca | WWG1DJK6 | 52.35238678 | 52.35238678 | 1 | In Stock | HUBBELL WIRING DEVICE-KELLEMS | 0.4 | 52.35238678 @ Qty: 1+ | ||
| Graybar | 25087297 | 54.2528 | 54.2528 | 1 | In Stock | Hubbell Wiring Device - Kellems | 54.2528 @ Qty: 1+ | |||
 | Radwell | HBL2411BK | 55.0 | 55.0 | 1 | In Stock | HUBBELL KELLEMS | 55.0 @ Qty: 1+ | ||
| us.rs-online.com | 70574828 | 59.84 | 59.84 | 1 | In Stock | Hubbell Wiring Device-Kellems | 59.84 @ Qty: 1+ | |||
 | Newark | 01J4255 | 60.61 | 60.61 | 1 | In Stock | HUBBELL WIRING DEVICES | 60.61 @ Qty: 1+ | ||
 | United Electric | 676001 | 64.34 | 64.34 | 1 | In Stock | WIRING DEVICE-KELLEMS | 64.34 @ Qty: 1+ | ||
 | Raptor Supplies | AA9JGN | 77.164191 | 77.164191 | 1 | In Stock | HUBBELL WIRING DEVICE-KELLEMS | 77.164191 @ Qty: 1+ | ||
| kirbyrisk.com | 2544737 | 83.61 | 83.61 | 1 | In Stock | Hubbell | 83.61 @ Qty: 1+ |
