mpn:
brand:
manufacturer:
MPN:
Weight:
0.1625
Weight:
0.1625 LB
Preferred Price:
23.96
Min Offer Price:
18.70
Price:
23.96
Min Simple Price:
12.31
Absolute Min Price:
17.84
Min Price:
17.84
Dimensions:
[10.0, 5.0, 4.0]
qty:
21
simpleSku:
MTQwNQ:::HBL5252R
sku:
MTQwNQ::1V:HBL5252R@y0
condition:
11
seller:
Zoro
amzMan:
cai - hubbell wiring device-kellems
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| AFCI, GFCI, Illuminated, Isolated Ground, Multimedia Outlet, Shrouded, Surge Protection, Surge Suppression, Tamper Resistant, USB, Weather Resistant | No |
| Amperage, Amps - Plugs and Receptacles, Current / amperage rating, Current rating, Current Rating | 15 A |
| Application Environment, Market | Industrial |
| Approvals | CSA, UL |
| Color, Color - Plugs and Receptacles, Housing Colour | Red |
| Comments | Extra Heavy Duty Compact |
| Connection Orientation | Straight |
| Connectivity | Back and Side Wired |
| Contact Material | Brass |
| Cover Type | No Cover |
| Dielectric strength | Withstands 2,000V minimum |
| Dimensions | 3.28 in x 1.33 in x 1.05 in |
| Display Size | Standard Sized Product |
| Environmental conditions | Indoor Dry Unless Protected By Additional Means |
| Face Plate Height | 2.73 in |
| Face Plate Width, Width | 1.33 in |
| Family Series | Hubbell Plugs & Receptacles |
| Flange Type | Non-Flanged |
| For Location | Indoor |
| Grade | Federal Specification |
| Gross Weight | 0.25 lbs |
| Grounding | Grounded |
| Height, Overall Depth | 1.05 in |
| Horsepower Rating | 1/2 hp |
| Housing Material | Nylon |
| HP, Max HP | 0.5 |
| Includes | Grounding Clip, Mounting Hardware, Wall Plate or Weatherproof Cover |
| Includes Mounting Hardware, Polarized | Yes |
| Item | Traditional Duplex |
| Item Number, Manufacturer Part Number | HBL5252R |
| Item, Item - Plugs and Receptacles | Receptacle |
| Length, Mount Hole Center-to-Center Height | 3.28 in |
| Manufacturer | Hubbell |
| Material - mounting hardware | Screw Mounting |
| Maximum Operating Temperature | 75 Degrees C |
| Maximum Wire Size | 10 AWG |
| Minimum Operating Temperature | -40 Degrees C |
| Minimum Wire Size | 14 AWG |
| Mount Type, Mounting Type - Plugs and Receptacles | Flush |
| NEMA Configuration | 5-15 |
| NEMA Configuration, Nema Rating, NEMA Receptacle Configuration, NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| NEMA Enclosure Rating, Number of Gangs, Phase | 1 |
| Net Weight | 0 lbs |
| Number of poles | 2-Pole |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Number of wires | 3-Wire |
| Operating temperature | Maximum continuous 75C and minimum -40C without Impact |
| Outlet Type - Plugs and Receptacles | Standard Duplex |
| Phase | Single, Single phase |
| Receptacle Type | Duplex |
| Standards | UL,CSA |
| Style | Finder Groove Face |
| UL 94 Flammability Rating | V-0 |
| Voltage | 125 VAC |
| Voltage - Plugs and Receptacles, Voltage Rating | 125V AC |
| Voltage rating description | 125 V |
| Wattage | 1875 W |
| Width (in) | 1.33 |
| Wire Connection Type | Screw Terminals |
| Wire Size, Wire size | #14 AWG to #10 AWG |
| Wiring Method | Back, Side |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G3332987 | 12.31 | 12.31 | 1 | 83 | Hubbell | 2.6 | 12.31 @ Qty: 1+ | |
| Onlinecomponents.com | HBL5252R | 12.92 | 12.92 | 1 | In Stock | Hubbell | 12.92 @ Qty: 1+ | |||
| grainger.ca | HBLHBL5252R | 13.98628162 | 13.98628162 | 1 | In Stock | HUBBELL WIRING DEVICE-KELLEMS | 0.25 | 13.98628162 @ Qty: 1+ | ||
| Grainger | 2LBV8 | 15.95 | 15.95 | 1 | 9 | 0 | HUBBELL WIRING DEVICE-KELLEMS | 15.95 @ Qty: 1+ | ||
 | gordonelectricsupply.com | HBL5252R | 17.4 | 17.4 | 1 | In Stock | HUBBELL | 17.4 @ Qty: 1+ | ||
| standardelectricsupply.com | 2234194 | 17.5 | 17.5 | 1 | In Stock | Hubbell | 17.5 @ Qty: 1+ | |||
 | MRO Supply | 1023718 | 17.5 | 24.5 | 2 | In Stock | Hubbell Wiring | 17.5 @ Qty: 2+ | ||
 | Galco | HBL5252R-HBBL | 18.01 | 18.01 | 1 | In Stock | Hubbell | 0.25 | 18.01 @ Qty: 1+ | |
| us.rs-online.com | 71987375 | 19.12 | 19.12 | 1 | In Stock | Hubbell Wiring Device-Kellems | 19.12 @ Qty: 1+ | |||
| AmazonSC | B00E2XS56C | 20.14 | 20.14 | 1 | In Stock | Hubbell Wiring Device-Kellems | 20.14 @ Qty: 1+ | |||
 | sustainablesupply.com | C1181444 | 20.96 | 20.96 | 1 | In Stock | Hubbell | 0.25 | 20.96 @ Qty: 1+ | |
 | Raptor Supplies | AC2MHZ | 29.989674 | 29.989674 | 1 | In Stock | HUBBELL WIRING DEVICE-KELLEMS | 29.989674 @ Qty: 1+ |
