Attributes
| Key ^ | Value |
|---|---|
| Amperage, Current Rating | 15 A |
| Amps | 15 |
| Application | Extra Heavy Duty Compact |
| Application Environment | Industrial |
| Brand | Hubbell Wiring Device-Kellems |
| Carton Quantity | 10 |
| Color | White |
| Connectivity | Side Wired Only |
| Corrosion Resistant, Power Indicator, Surge Suppression, Tamper Resistant, Weather Resistant | No |
| Country of Origin (subject to change) | United States |
| Description | Grounding |
| Dielectric Strength | Withstands 2,000V minimum |
| Dimensions | 3.28 in x 1.33 in x 1.05 in |
| Display Size | Standard Sized Product |
| Environmental Rating | Indoor Dry Unless Protected By Additional Means |
| Height | 1.05 in |
| HP, Maximum Horsepower | 0.5 |
| Item | Traditional Duplex |
| Length | 3.28 in |
| Material | Nylon/Reinforced PET |
| Mounting Hardware Material | Screw Mounting |
| Mounting Type | Flush |
| NEMA Configuration, Nema Rating | 5-15R |
| Number of Gangs | 1 |
| Number Of Poles | 2-Pole |
| Number of Poles | 2 |
| Number Of Wires | 3-Wire |
| Number of Wires | 3 |
| Operating Temperature | Maximum continuous 75?C and minimum -40?C without Impact |
| Outlet Type | Duplex |
| Phase | Single Phase |
| Series | Heavy Duty |
| Standards | UL listed, CSA certified |
| Style | Finder Groove Face |
| Sub-Category | Duplex Receptacles |
| Type | Standard Duplex |
| UPC | 783585000000 |
| Voltage | 125VAC |
| Voltage Rating | 125 VAC |
| Wattage | 1875 W |
| Weight | 0.2 lb |
| Width | 1.33 in |
| Wire Size | #14 AWG to #10 AWG |
| Wiring Method | Side |
