| Action | SPDT |
| Amperage Rating, Current / Amperage Rating, Current Rating | 20 A |
| Class Code | A16 |
| Color | White |
| Country of Origin | PR |
| Description - Invoice | SWITCH,SNAPCONN,3W,20A120/277V,WH,NA |
| Dielectric Strength | Withstands 1500V AC minimum for 1 minute |
| Dimensions, Size | 4.18 in x 1.3 in x 1.74 in |
| Each - Height | 1.660 in |
| Each - Length | 4.160 in |
| Each - Width | 1.910 in |
| EU RoHS Indicator | Yes |
| Freight Class Code | 06168002 |
| Harmonization Code | 8536509040 |
| Height | 1.74 in |
| Image Actual Or Representative | A |
| Industry Standard(s), Standard | UL Listed |
| Length | 4.18 in |
| Material | Thermoplastic |
| MSDS Flag | No |
| Number of Poles, Number Of Poles | Single Pole |
| Operating Temperature | Maximum continuous 75?C and minimum -40?C without Impact |
| Performance : Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute;Electrical - Max. Continuous Current - 20A;Electrical - Max. Working Voltage - 277V AC;Electrical - Overload - Minimum 4.8 times rated current for 100 cycles;Electrical - Temperature Rise - 30?C maximum at rated current;Environmental - Flammability - UL 94V-2;Environmental - Operating Temperature - Max. continuous: 75?C, Min. continuous | -40?C without impact;Mechanical - Terminal Accommodations - Uses SNAPConnect Connector |
| Series | General Purpose |
| Special Features | SNAP Connect, Automatic self-grounding |
| Style | Three Way |
| Sub Class Code | A16A250 |
| Temperature Rise - Max. | 30?C maximum at rated current |
| Type | Toggle |
| Voltage Rating, Voltage Rating Description | 120-277 VAC |
| Width | 1.3 in |
